Denon AVR-390 Service Manual

51
DHT-390XP
AVR-390
ZD106 90M-HD302420R D,ZENER MTZJ2.4B K06002R444520S
ZD107 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD108 00D9600128105 D,ZENER MTZJ9.1B K06009R144520S
LED701 00D9630366108 LED BL-BEG204-L 5PI K500052004010S
RESISTORS GROUP
R142,143 00D9630048103 R,METAL FILM 150-J,1W
C060015165050S
R156C nsp R,METAL FILM 10-J,1W C060010065050S
R156L nsp R,METAL FILM 10-J,1W C060010065050S
R156R nsp R,METAL FILM 10-J,1W C060010065050S
R156SL nsp R,METAL FILM 10-J,1W C060010065050S
R156SR nsp R,METAL FILM 10-J,1W C060010065050S
R157,158 nsp R,METAL FILM 470-J,2W C060047166060S
R174-176 00D9630310404 R,METAL FILM 2.2K-J,1W C060022265050S
R178,179 00D9630144502 R,CEMENT 0.1-J 5W C141R10069000S
R184 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R186 00D9639005655 R,METAL FILM 22-J,1/4W C060022063050S
R190 00D9630310501 R,METAL FILM 47K-J,1/4W C060047363050S
R205-208 00D9630216003 R,METAL FILM 0.22-J,1W C060R22065050S
CAPACITORS GROUP
C101L nsp C,CERAMIC 100PF-J/50V
D010101167160S
C101R nsp C,CERAMIC 100PF-J/50V D010101167160S
C102L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C102R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C103L nsp C,CERAMIC 100PF-J/50V D010101167160S
C103R nsp C,CERAMIC 100PF-J/50V D010101167160S
C104L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C104R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C105L nsp C,CERAMIC 220PF-J/50V D010221167160S
C105R nsp C,CERAMIC 220PF-J/50V D010221167160S
C106L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C106R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C107L nsp C,CERAMIC 220PF-J/50V D010221167160S
C107R nsp C,CERAMIC 220PF-J/50V D010221167160S
C108L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C108R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C109L nsp C,CERAMIC 220PF-J/50V D010221167160S
C109R nsp C,CERAMIC 220PF-J/50V D010221167160S
C110L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C110R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C111L nsp C,CERAMIC 220PF-J/50V D010221167160S
C111R nsp C,CERAMIC 220PF-J/50V D010221167160S
C112L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C112R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C113L nsp C,CERAMIC 220PF-J/50V D010221167160S
C113R nsp C,CERAMIC 220PF-J/50V D010221167160S
C114L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C114R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C115C nsp C,CERAMIC 100PF-J/50V D010101167160S
C115L nsp C,CERAMIC 100PF-J/50V D010101167160S
C115R nsp C,CERAMIC 100PF-J/50V D010101167160S
C115SL nsp C,CERAMIC 100PF-J/50V D010101167160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-390 Specifications

General

Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Wi-Fi	No
Input Impedance	47k ohms
Inputs	Digital coaxial x 1
Outputs	HDMI x 1
