Denon AVR-390 Service Manual

50
DHT-390XP
AVR-390
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 963243003090D IC. CPU MICRO PROCESS
(IC UPD78F0537GK)"
8952390000010
IC102 00D9630278300 IC NJW1153
J084115300010S
IC103 00D9600100301 IC KIA7812API J126781200040S
IC104 00D2631099022 IC KIA7912PI J126791200060S
IC105 00D9600295902 IC CF4558CB J121455800150S
IC202 90M-HC110000R IC MC24C08-WMN6 J000240860010S
IC522 00D9600100301 IC KIA7812API J126781200040S
IC523 00D2631100063 IC KIA7809API J126780900020S
Q103,104 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q105 963219003170S TR KRA105S(PE) J520010500210S
Q106 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q107 963219003170S TR KRA105S(PE) J520010500210S
Q108 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q109 963219003170S TR KRA105S(PE) J520010500210S
Q110 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q111 963219003170S TR KRA105S(PE) J520010500210S
Q114,115 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q116-118 90M-BA001650R TR KRC105S (NE) J522010500210S
Q120 90M-BA001650R TR KRC105S (NE) J522010500210S
Q121 00D9600196302 TR KTA1268BL J5001268B0050S
Q122 00D9600005202 TR KTC3198Y J5023198Y0000S
Q123,124 00D9600196302 TR KTA1268BL J5001268B0050S
Q125 00D9600133103 TR KSA916Y J5000916Y0050S
Q126 00D9600196302 TR KTA1268BL J5001268B0050S
Q127 00D9600005202 TR KTC3198Y J5023198Y0000S
Q128 00D9600196302 TR KTA1268BL J5001268B0050S
Q129,130 00D9600005202 TR KTC3198Y J5023198Y0000S
Q131 00D9600196302 TR KTA1268BL J5001268B0050S
Q132,133 00D9600005202 TR KTC3198Y J5023198Y0000S
Q134 00D9600196302 TR KTA1268BL J5001268B0050S
Q135,136 00D9600005202 TR KTC3198Y J5023198Y0000S
Q137,138 00D9630121509 TR KTC3875S J522038750210S
D101-110 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D116-121 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D122 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D123,124 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D126-128 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D129-134 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D135-137 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D142 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D705-708 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD101,102 90M-HZ300080R D,ZENER 0.2W 7.5V UDZ K06607R54P400S
ZD103,104 90M-HZ300090R D,ZENER 0.2W 16V UDZ K06616R04P400S
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.

Denon AVR-390 Specifications

General

Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Wi-Fi	No
Input Impedance	47k ohms
Inputs	Digital coaxial x 1
Outputs	HDMI x 1
