Denon AVR-390 Service Manual

58
DHT-390XP
AVR-390
C212 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
OTHERS PARTS GROUP
CN110 nsp CN,WIRE 100MM/10P
L002101100060S
CN111 nsp CN,WIRE 120MM/13P L000121130040S
L201C 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L201FL 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L201FR 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L201SL 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L201SR 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
TP201C nsp CN.WAFER 3P ANGLE L101530150310S
TP201FL nsp CN.WAFER 3P ANGLE L101530150310S
TP201FR nsp CN.WAFER 3P ANGLE L101530150310S
TP201SL nsp CN.WAFER 3P ANGLE L101530150310S
TP201SR nsp CN.WAFER 3P ANGLE L101530150310S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-390 Specifications

General

Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Wi-Fi	No
Input Impedance	47k ohms
Inputs	Digital coaxial x 1
Outputs	HDMI x 1
