Denon AVR-390 Service Manual

62
DHT-390XP
AVR-390
POWER P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC300 00D9630300702 IC LM1117S-3.35V
J126111733030S
Q300,301 00D9630121509 TR KTC3875S J522038750210S
Q302 00D9630121606 TR KRC107S E3 J522107S00210S
D302-304 00D9630219709 D,SWITCHING 1N4148W K005041480020S
D305-308 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD301 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
ZD302 963202003190S D,ZENER 0.2W 10V UDZ E3 K06610R04P400S
RESISTORS GROUP
R304 nsp R,CARBON 27-J,1/4W
C000027063520S
CAPACITORS GROUP
C300 00D9630234205 C,ELECT 10UF-M/50V
D040100087070S
C301 00D9600133501 C,ELECT 2200UF-M/16V D040222083080S
C302 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
z
C304 00D9630323802 C,CERAMIC 0.0047UF 250VAC D00847208H010S
C315 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
OTHERS PARTS GROUP
CN103 nsp CN.FPC 1.25MM
L131007000010S
z
CP305 nsp CN.WAFER 2CKT,YEL L108353280290S
z
CP306 nsp CN.WAFER ST2P L108202000220S
z
F301 00D9630104908 FUSE T6.3A /250V E3 N751226301110S
z
F301 00D9630237600 FUSE GLASS TUBE 20MM T4A E2 N751224001110S
F301A nsp HOLDER,FUSE CLIP G645000050010S
z
F301B nsp HOLDER,FUSE CLIP G645000050010S
z
J301 nsp Jumper
z
RLY301 90M-LY000390R RELAY G5PA-1 DC6V 5A G680060502010S
z
SUB301 963101002860S POWER TRANS RD6502B(A) E3 8200280150280S
z
SUB301 90M-TS003070R POWER TRANS RD6502S(G) E2 8200280150290S
GT301 nsp TERMINAL EARTH 3790040886000S
LABEL nsp LABEL FUSE E3 5507000003470S
