Denon AVR-390 Service Manual

64
DHT-390XP
AVR-390
C468 nsp C,CERAMIC CHIP T.C COG22PF-J/50V-
1608REEL
D010220167160S
C469 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C470 nsp C,CERAMIC 100PF-J/50V D010101167160S
C471 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C472 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C473 nsp C,CERAMIC22PF-J/50V D010220167160S
C474 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C475 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C476 00D9630293806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C477 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C478 00D9630293806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C479 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C480 nsp C,CERAMIC 100PF-J/50V D010101167160S
C481,482 nsp C,CERAMIC 27PF-J/50V D010270167160S
C483,484 nsp C,CERAMIC 220PF-J/50V D010221167160S
C485,486 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C487 nsp C,CERAMIC 100PF-J/50V D010101167160S
C489 nsp C,CERAMIC 100PF-J/50V D010101167160S
C490 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C491 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C492 nsp C,CERAMIC 100PF-J/50V D010101167160S
C493 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
OTHERS PARTS GROUP
CB401-403 963115003230S COIL,BEAD CBW160808U121T
D340160811210S
CB405-413 963115003230S COIL,BEAD CBW160808U121T D340160811210S
CB415-420 963115003230S COIL,BEAD CBW160808U121T D340160811210S
CN401 nsp CN.WAFER 15P L101100031510S
CN402 nsp CN.WAFER 18P L101100031810S
CN403 nsp CN.WAFER 5P L101100030510S
CP01 nsp CN.WAFER 9P L101200100920S
JACK402 00D9630237503 MODULE JSR1165-C E100116500040S
L401,402 00D9630050900 COIL INDUCTOR 2.2UH D3302R2000150S
XTAL401 00D9630217303 CRYSTAL 12.288MHZ E80012R288090S
00D9630294601 JACK,D3.5 EARPHONE G40100350000YS
00D9630217905 TER,RCA 2PIN G601206A0200YS
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-390 Specifications

General

Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Wi-Fi	No
Input Impedance	47k ohms
Inputs	Digital coaxial x 1
Outputs	HDMI x 1
