Denon AVR-390 Service Manual

70
DHT-390XP
7 00D9630362202 BADGE DENON SPE2 5630210028400S 1
8 963402002780D PANEL FRONT BKE3
3067214141000S 1*
8 963402002970D PANEL FRONT BKE2
3067214141100S 1*
8 963402002910D PANEL FRONT SPE2
3067214141200S 1*
9 00D9630137807 LENS STANDBY
3710210503000S 1
10 963411002820S BUTTON-ASSY STANDBY(KD) BKE3,BKE2
5098212361000SZ 1*
10 00D9630221904 BUTTON-ASSY STANDBY SPE2
5097212368030SZ 1
15 00D9630365002 BUTTON WIN 3KEY BKE3,BKE2
5097213371000S 2
15 00D9630365301 BUTTON WIN 3KEY SPE2
5097213371110S 2
16 00D9630365404 BUTTON WIN 6KEY BKE3,BKE2
5097213361000S 1
16 00D9630365703 BUTTON WIN 6KEY SPE2
5097213361110S 1
18 nsp HEAT SINK MAIN
2120210538100S 1*
19 nsp BRACKET H SINK
4010056906010S 5*
22 963407003060S FOOT ASSY
4000040201020S 4*
23 nsp CHASSIS MAIN
3200200026050S 1*
24 nsp CUSHION UP-CNT1
4050211665000S 2
25 nsp SPACER
4300040561010S 6*
z 28 963101002870S POWER TRANS BKE3
8200960560180S 1*
z 28 963101003050S POWER TRANS BKE2,SPE2
8200960560190S 1*
34 963406003040D CHASSIS BACK BKE3
3207212636000S 1*
34 963406003030D CHASSIS BACK BKE2,SPE2
3207212636010S 1*
z 35 nsp STOPPER
4380040162010S 1*
z 36 963611003020S CORD ASSY BKE3
L068125100050S 1*
z 36 90M-YC000960R CORD ASSY BKE2,SPE2
L068250250100S 1*
37 963403002770D CABINET TOP BKE3,BKE2
3000211236000S 1*
37 963401002900D CABINET TOP SPE2
3000211236100S 1*
38 nsp CLAMP WIRE(MTG)
4330000310000S 4
39 nsp CUSHION
4050211365000S 1*
40 nsp CUSHION
4050210485000S 1*
41 00D9600187900 POSISTOR
F320171020240S 1
42 nsp SHEET CABINET
1210210235000S 4*
★ 45
00D9960018706 TR PNP 2SB1560-Y
Q206C,Q206FL,Q206FR,
Q206SL,Q206SR
J5011560Y0000S 5
★ 46
00D9630280107 TR NPN 2SC3964
Q204C,Q204FL,Q204FR,
Q204SL,Q204SR
J502396400000S 5
★ 47
00D9960018706 TR NPN 2SD2390-Y
Q205C,Q205FL,Q205FR,
Q205SL,Q205SR
J5032390Y0000S 5
★ 48
963606003010S CABLE,FLAT CARD 1.25MM
N712192233810S 1
★ 49
nsp CLAMP
4330040343010S 3
SCREWS
Ansp
SCREW,TAP TITE(+2S 3*8 B-TYPE ZNW/BH) B020030081B10S 60
B nsp SCREW,TAP TITE(+2S 3*8 B-TYPE BK/BH) BKE3,BKE2
B020030083B10S 3*
B nsp SCREW,TAP TITE(+2S 3*8 B-TYPE NI/BH) SPE2
B020030084B10S 3*
C nsp SCREW(+2S 3*16+S-WASHER ZNW/HH)
1507041146010S 15 *
D nsp SCREW,TAP TITE ASSY(+3S 4*10 P+S-
WASHER ZNW/BH)
B028940101B10S 4
E nsp SCREW,TAP TITE(3X18 B-TYPE ZNW/BH)
B020030181B10S 6*
F nsp SCREW(+2S 3*8 ZnY WASHER PI12)
1500001456010S 1
Gnsp
SCREW,TAP TITE(+2S 3*10 B-TYPE(DOT) BK/BH) B020030103B11S 33
H 00D9630048307 SCREW(+2S 4*8 B-TYPE(DOT) BK/BH) BKE3,BKE2
1500040083B10S 6
H 00D9639004012 SCREW(+2S 4*8 B-TYPE(DOT) NI/BH) SPE2
1500040084B10S 6
J nsp SCREW,TAP TITE(+3S 3*8 BK/BH)
B020930083B10S 3
Ref. No. Part No. Part Name Remarks Q'ty New
AVR-390

Denon AVR-390 Specifications

General

Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Wi-Fi	No
Input Impedance	47k ohms
Inputs	Digital coaxial x 1
Outputs	HDMI x 1
