Zone Setup
Make settings for audio playback in a multi-
zone system.
F Menu tree F
Manual Setup
Zone Setup
a ZONE2
s ZONE3
a
ZONE2
Make settings for audio playback in a ZONE2 system.
s
ZONE3
Make settings for audio playback in a ZONE3 system.
Bass
Adjust low frequency range (bass).
[Variable range] –10dB
~
0dB
~
+10dB
Treble
Adjust high frequency range (treble).
[Variable range] –10dB
~
0dB
~
+10dB
HPF
When using speakers that cannot satisfactorily play low frequencies,
distortion of the bass sound can be reduced by setting “HPF” to
“ON”.
[Selectable items] ON
OFF
Lch Level
Adjust the left channel output level.
[Variable range] –12dB
~
0dB
~
+12dB
Rch Level
Adjust the right channel output level.
[Variable range] –12dB
~
0dB
~
+12dB
Channel
Switch between stereo and mono output.
[Selectable items] Stereo
Mono
When GUI menu “Manual Setup” – “Option Setup” – “Amp Assign”
(vpage 37) is set to “ZONE (MONO)”, “Bi-Wiring & ZONE (MONO)”
or “ZONE2/3 (MONO)”, the “Channel” setting is automatically set to
“Mono”.
Volume Level
Adjust the main volume level.
[Selectable items] Variable
–40dB
0dB
“Variable” is displayed when a power amplifier is assigned to the
ZONE2 output channel at GUI menu “Manual Setup” – “Option Setup”
– “Amp Assign”(vpage 37).
Volume Limit
Make a setting for maximum volume.
[Selectable items] OFF
–20dB
–10dB
0dB
Power On Level
Define the volume setting that is active when the power is turned on.
[Selectable items] Last
– – –
–70dB ~ 18dB
Mute Level
Set the amount of attenuation when muting is on.
[Selectable items] Full
–40dB
–20dB
Setup
