Denon AVR-4308CI

Video Convert
SIGNAL IN MONITOR OUT (Normally) MONITOR OUT (when GUI menu displayed)
HDMI COMPONENT S-VIDEO VIDEO HDMI COMPONENT S-VIDEO VIDEO HDMI COMPONENT S-VIDEO VIDEO
OFF
A A A A A A A A S S S S
A A A S A A A S (VIDEO) S S S S
A A S A A A S (S-VIDEO) A S S S S
A A S S A A S (S-VIDEO) S (VIDEO) S S S S
A S A A A S (COMPONENT) A A S S S S
A S A S A S (COMPONENT) A S (VIDEO) S S S S
A S S A A S (COMPONENT) S (S-VIDEO) A S S S S
A S S S A S (COMPONENT) S (S-VIDEO) S (VIDEO) S S S S
S A A A S (HDMI) A A A S (HDMI)
z
2 A A A
S A A S S (HDMI) A A S (VIDEO) S (HDMI)
z
2 A A A
S A S A S (HDMI) A S (S-VIDEO) A S (HDMI)
z
2 A A A
S A S S S (HDMI) A S (S-VIDEO) S (VIDEO) S (HDMI)
z
2 A A A
S S A A S (HDMI) S (COMPONENT) A A S (HDMI)
z
2 A A A
S S A S S (HDMI) S (COMPONENT) A S (VIDEO) S (HDMI)
z
2 A A A
S S S A S (HDMI) S (COMPONENT) S (S-VIDEO) A S (HDMI)
z
2 A A A
S S S S S (HDMI) S (COMPONENT) S (S-VIDEO) S (VIDEO) S (HDMI)
z
2 A A A
S : Signal present
A : No signal
S : Output present
A : No output
z
2 : Superimposed over video signal
To display the GUI menu on an HDMI monitor, output with a resolution of 480p/576p.
84
Getting Started Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
Input
MONITOR OUT
COMPONENT S-VIDEO VIDEO COMPONENT VIDEO
A A A A A
A A S A S (VIDEO)
A S A A S (S-VIDEO)
A S S A S (S-VIDEO)
S A A S (COMPONENT) A
S A S S (COMPONENT) S (VIDEO)
S S A S (COMPONENT) S (S-VIDEO)
S S S S (COMPONENT) S (S-VIDEO)
S : Output present
A : No output
: On-screen display not displayed
S : Signal present
A : No signal
n ZONE2
