SPECIFICATIONS
2 Audio section
• Power amplifier
Rated output: Stereo (2ch driven)
(All properties shown are only 140 W + 140 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
for the power amplifier stage.) 170 W + 170 W (8 Ω/ohms, 1 kHz with 0.7% T.H.D.)
Surround
140 W x 5 ch (8 Ω/ohms, 1 kHz with 0.7% T.H.D.)
Dynamic power: 190 W x 2 ch (8 Ω/ohms)
310 W x 2 ch (4 Ω/ohms)
390 W x 2 ch (2 Ω/ohms)
Output terminals: Front/Center: 16 ~ 16 Ω/ohms
Surround: A or B 16 ~ 16 Ω/ohms
A + B 12 ~ 16 Ω/ohms
• Analog
Input sensitivity / input impedance: 200 mV / 47 kΩ/kohms
Frequency response: 10 Hz ~ 100 kHz: +0, –3 dB (DIRECT mode)
S/N: 105 dB (DIRECT mode)
Distortion: 0.005% (20 Hz ~ 20 kHz) (DIRECT mode)
Rated output/maximum output: 1.2 V / 8 V
Maximum headphones output: 284 mW (8 Ω/ohms)
• Digital
D/A output: Rated output — 2 V (at 0 dB playback)
Total harmonic distortion — 0.005% (1 kHz, at 0 dB)
S/N ratio — 105 dB
Dynamic range — 96 dB
Digital input: Format — Digital audio interface
• Phono equalizer (PHONO input — REC OUT)
Input sensitivity: 2.5 mV
RIAA deviation: ±1 dB (20 Hz to 20 kHz)
Signal-to-noise ratio: 74 dB (A weighting, with 5 mV input)
Rated output / Maximum output: 150 mV / 8 V
Distortion factor: 0.03% (1 kHz, 3 V)
2 Video section
• Standard video jacks
Input / output level and impedance: 1 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz — +0, –3 dB
• S-video jacks
Input / output level and impedance: Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
C (color) signal — 0.286 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz — +0, –3 dB
• Color component video terminal
Input / output level and impedance: Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
Cb (blue) signal — 0.7 Vp-p, 75 Ω/ohms
Cr (red) signal — 0.7Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 20 MHz — +0, –3 dB
2 Tuner section
[FM] (note: µV at 75 Ω/ohms, 0 dBf = 1 x 10
–15
W) [AM]
Receiving Range: 87.5 MHz ~ 107.9 MHz 520 kHz ~ 1710 kHz
Usable Sensitivity: 1.0 µV (11.2 dBf) 18 µV
50 dB Quieting Sensitivity: MONO 1.6 µV (15.3 dBf)
STEREO 23 µV (38.5 dBf)
Signal to Noise Ratio (IHF-A): MONO 80 dB 50 dB
STEREO 75 dB
Total Harmonic Distortion (at 1 kHz): MONO 0.15%
STEREO 0.3%
2 General
Power supply: AC 120 V, 60 Hz
Power consumption: 11 A
Maximum external dimensions: 434 (W) x 181 (H) x 494 (D) mm (17-3/32” x 7-1/8” x 19-29/64”)
Weight: 21.5 kg (47 lbs 6 oz)
2 Remote control unit (RC-853)
Batteries: R6P/AA Type (two batteries)
External dimensions: 70 (W) x 215 (H) x 24 (D) mm (2-3/4” x 8-15/32” x 15/16”)
Weight: 200 g (Approx. 7 oz) (including batteries)
* For purposes of improvement, specifications and design are subject to change without notice.
