14
AVR-5805/AVC-A1XV-UPGRADE
17 P87/XCIN (XMDACRST) O C - - (-) Z O/L (DAC control terminal for XM(AK4385ET))
18 P86/XCOUT (XMDACMUTE) O C - - (-) Z O/L (DAC output MUTE control terminal for XM )
19 RESET RESET I - Lv - Eu L I Reset input(Reset:"L")
20 XOUT X2 O - - - - - - Clock output
21 VSS VSS - - - - - - - GND
22 XIN X1 I - - - - - I Clock input
23VCC VCC ---- ---+3.3V
24 P85/NMI _NMI I - - - - - - Not used(Fixed:"H")
25 P84/INT2 (REMOTE) I -
E↑&L
- Ed Z I Remote control signal input(TEST:usually unused thing)
26 P83/INT1 V.B.DOWN I -
E↓&L
- Eu Z I Power down detect (Power down: L)
27 P82/INT0 (REQ XM) O C - - (-) Z O/L (XM RADIO terminal for control)
28 P81/ (XMDACCS) O C - - (-) Z O/L (DAC control terminal for XM(AK4385ET))
29 P80/ISRXD0 (RXD MIXMO) O C - - (-) Z O/L (XM RADIO terminal for control)
30 P77/ISCLK0 (XMDACMC) O C - - (-) Z O/L (DAC control terminal for XM(AK4385ET))
31 P76/ISTXD0 (TXD MOXMI) O C - - (-) Z O/L (XM RADIO terminal for control)
32 P75/ISRXD1 (RXD iPod) O C - - (-) Z O/L (IPOD communication control terminal)
33 P74/ISCLK1 (iPOD CON DET) O C - - (-) Z O/L (IPOD detect terminal("L": DETECT)
34 P73/CTS2/ISTXD1 (TXD_iPod) O C - - (-) Z O/L (IPOD communication control terminal)
35 P72/CLK2 CLK VIMO I - Lv - - Z O/L MAIN-VIDEO communication control terminal
36 P71/RXD2/ VIMO I - Lv - Eu Z O/L MAIN-VIDEO communication control terminal
37 P70/TXD2/ VOMI O N - - Eu Z O/L MAIN-VIDEO communication control terminal
38 P67/TXD1 FRONT TxD O C - - - Z O/L Data transfer terminal to outside(MAKER BOOT)
39VCC VCC ---- ---+3.3V
40 P66/RXD1 FRONT RxD I - Lv - - Z O/L Data reception terminal from Ext.(MAKER BOOT)
41 VSS VSS - - - - - - - GND
42 P65/CLK1 REQ VOMI O C - - - Z O/L MAIN-VIDEO communication control terminal
43 P64/CTS1 VSEL0 O C - - - Z O/L BUS SW(FPGA)switching control terminal
44 P63/TXD0 ZONE1 SDA I/O C - - - Z O/L VIDEO I2C control terminal
45 P62/RXD0 ZONE1 SCL I/O C - - - Z O/L VIDEO I2C control terminal
46 P61/CLK0 Z2 VSIG DET I - Lv - Eu Z O/L ZONE2 VIDEO IN signal detect input(signal input:"H")
47 P60/CTS0 Z1 VSIG DET I - Lv - Eu Z O/L MAIN ZONE VIDEO IN signal detect input(signal input:"H")
48 P137 Z1 OSD RST O C - - - Z O/L MAIN OSD control terminal(M35015)
49 P136/ISCLK2 Z1 OSD CLK O C - - - Z O/L MAIN OSD control terminal(M35015)
50 P135/ISRXD2 Z1 OSD STB O C - - - Z O/L MAIN OSD control terminal(M35015)
51 P134/ISTXD2 Z1 OSD DATA O C - - - Z O/L MAIN OSD control terminal(M35015)
52 P57 ZONE2 SDA I/O C - - - Z O/L ZONE2 VIDEO I2C control terminal(TA1270/TC90A69F)
53 P56 ZONE2 SCL I/O C - - - Z O/L ZONE2 VIDEO I2C control terminal(TA1270/TC90A69F)
54 P55/EPM FRASH EPM I - - - Ed Z I Rewrite boot program start: "L" Input setting
55 P54 Z1 SMONIDET I - Lv - Eu Z O/L S MONITER connection detect input for MNAIN ZONE (Connected:"L")
56 P133 Z2 S SIG DET I - Lv - Eu Z O/L MAIN ZONE S signal detect input(Connecte:"H")
57 VSS VSS - - - - - - - GND
58 P132 Z1 S SIG DET I - Lv - Eu Z O/L MAIN ZONE S signal detect input(Connecte:"H")
59VCC VCC ---- ---+3.3V
60 P131 Z2 SMONIDET I - Lv - Eu Z O/L S MONITER connection detect input for ZONE2(Connected:"L")
61 P130 SV EXP OE O C - - Ed Z O/L Control terminal switching for COMPONENT section, Expander control(BU4094B)
62 P53 SV EXP STB O C - - - Z O/L Control terminal switching for COMPONENT section, Expander control
63 P52 SV EXP DATA O C - - - Z O/L Control terminal switching for COMPONENT section, Expander control(BU4094B)
64 P51 SV EXP CLK O C - - - Z O/L Control terminal switching for COMPONENT section, Expander control
65 P50/CE FRASH CE I - - - Ed Z I Rewrite boot program start:H input set
66 P127 C EXP OE O C - - Ed Z O/L Control terminal switching for COMPONENT section, Expander control(BU4094B)
67 P126 C EXP STB O C - - - Z O/L Control terminal switching for COMPONENT section, Expander control(BU4094B)
68 P125 C EXP DATA O C - - - Z O/L Control terminal switching for COMPONENT section, Expander control(BU4094B)
69 P47/CS0/A23 C EXP CLK O C - - - Z O/L Control terminal switching for COMPONENT section, Expander control(BU4094B)
70 P46/CS1/A22 COMP SDET1 I - Lv - Eu Z O/L COMPONENT IN signal detect input for MAIN ZONE
71 P45/CS2/A21 COMP SDET2 I - Lv - Eu Z O/L COMPONENT IN signal detect input for ZONE2
72 P44/CS3/A20 Z2 OSD RST O C - - - Z O/L ZONE2 OSD control terminal(M35015)
73 P43/A19 Z2 OSD STB O C - - - Z O/L ZONE2 OSD control terminal(M35015)
74VCC VCC ---- ---+3.3V
75 P42/A18 Z2 OSD CLK O C - - - Z O/L ZONE2 OSD control terminal(M35015)
76 VSS VSS - - - - - - - GND
77 P41/A17 Z2 OSD DATA O C - - - Z O/L ZONE2 OSD control terminal(M35015)
78 P40/A16 Z2 SYNC DET I - Lv - Eu Z O/L Synchronous detect input for ZONE2(Ext.Synchronous:H)
79 P37/D15 Z1 SYNC DET I - Lv - Eu Z O/L Synchronous detect input for MAIN(Ext.Synchronous:H)
80 P36/D14 OSDOUTSEL O C - - Ed Z O/L MAIN OSD Routing control
81 P35/D13 OSDRST O C - - - Z O/L NEW OSD control terminal(LC74731W)
82 P34/D12 OSDCLK O C - - - Z O/L NEW OSD control terminal(LC74731W)
83 P33/A11 OSDSIN O C - - - Z O/L NEW OSD control terminal(LC74731W)
84 P32/D10 OSDCS O C - - - Z O/L NEW OSD control terminal(LC74731W)
85 P31/D9 OSDMUTE O C - - - Z O/L NEW OSD control terminal(LC74731W)
86 P124 V/Y SEL O C - - Ed Z O/L MAIN NEW OSD control of input signal selection(S/CVBS)(TC4053)
87 P123 Y/C SEL O C - - Ed Z O/L Croma Decoder SELECT for ZONE2
88 P122/ISRXD3 VÇéCONFIG O C - - - Z O/L FPGA rewrite control terminal
89 P121/ISCLK3 V DATAOUT O C - - - Z O/L FPGA rewrite control terminal
90 P120/ISTXD3 V ASDI O C - - - Z O/L FPGA rewrite control terminal
91VCC VCC ---- ---+3.3V
92 P30/D8 VnCS O C - - - Z O/L FPGA rewrite control terminal
93 VSS VSS - - - - - - - GND
Pin Pin name Symbol I/O Type Det Op(Int.) Op(Ext.) Res stop Function
