15
AVR-5805/AVC-A1XV-UPGRADE
94 P27/AN27/D7 VDCLK O C - - - Z O/L FPGA rewrite control terminal
95 P26/AN26/D6 VCONF_DONE I - Lv - - Z O/L FPGA rewrite control terminal
96 P25/AN25/D5 VCPUASON O C - - - Z O/L
Rewrite for FPGAROM ON=L ※ Initial setting, V.POWER OFF=H
97 P24/AN24/D4 VnCE O C - - - Z O/L FPGA rewrite control terminal
98 P23/AN23/D3 VSEL5 O C - - - Z O/L BUS SW(FPGA) switching control terminal
99 P22/AN22/D2 VSEL4 O C - - - Z O/L BUS SW(FPGA) switching control terminal
100 P21/AN21/D1 VSEL3 O C - - - Z O/L BUS SW(FPGA) switching control terminal
101 P20/AN20/D0 VSEL2 O C - - - Z O/L BUS SW(FPGA) switching control terminal
102 P17/INT5/D15 VSEL1 O C - - - Z O/L BUS SW(FPGA) switching control terminal
103 P16/INT4/D14 ACK VIMO I -
E↑&L
- - Z O/L MAIN-VIDEO communication Control terminal
104 P15/INT3/D13 HDMIVS. I -
E↓&L
- - Z O/L HDMI V SYNC input terminal for count
105 P14/D12 TDO O C - - - Z O/L JTAG terminal for rewriting
106 P13/D11 FPGATDI I - Lv - - Z O/L JTAG terminal for rewriting
107 P12/D10 TMS O C - - - Z O/L JTAG terminal for rewriting
108 P11/D9 TCK O C - - - Z O/L JTAG terminal for rewriting
109 P10/D8 HDMI IN1 O C - - Ed Z O/L HDMI input selection control terminal
110 P07/AN07/D7 HDMI IN2 O C - - Ed Z O/L HDMI input selection control terminal
111 P06/AN06/D6 HDMI IN3 O C - - Ed Z O/L HDMI input selection control terminal
112 P05/AN05/D5 HDMI R RST1 O C - - Ed Z O/L Reset for HDMI RECEIVER(Si I9031)(DVI/HDMI1)
113 P04/AN04/D4 HDMI R RST2 O C - - Ed Z O/L Reset for HDMI RECEIVER(Si I9031)(HDMI2/3)
114 P114 HDMI R RST3 O C - - Ed Z O/L Reset for HDMI RECEIVER(Si I9031)(HDMI4/5)
115 P113 SCDT I - Lv - - Z O/L HDMI RECEIVER(Si I9031) SCDT output detection
116 P112/ INT I - Lv - - Z O/L HDMI RECEIVER(Si I9031) INT output detection
117 P111/ WPCPU1 O C - - - Z O/L WRITE PROTECT terminalfor HDMI IN EDIT(24LC02)
118 P110/ WPCPU2 O C - - - Z O/L WRITE PROTECT terminalfor HDMI IN EDIT(24LC02)
119 P03/AN03/D3 PRMVCPU1 O C - - - Z O/L HDMI IN Terminal, HP DET control terminal
120 P02/AN02/D2 PRMVCPU2 O C - - - Z O/L HDMI IN Terminal, HP DET control terminal
121 P01/AN01/D1 AUDIO1 O C - - - Z O/L HDMI AUDIO selection
122 P00/AN00/D0 AUDIO2 O C - - - Z O/L HDMI AUDIO selection
123 P157/AN157 AUDIO3 O C - - - Z O/L HDMI AUDIO selection
124 P156/AN156 HDMI T RST1 O C - - Ed Z O/L Reset for HDMI TRANSMITTER (Si I9030)
125 P155/AN155 HDMI SENS1 I -
E↓&L
- - Z O/L HDMI IN signal detect input
126 P154/AN154 HDMI T RST2 O C - - Ed Z O/L Reset for HDMI TRANSMITTER (Si I9030)
127 P153/AN153 HDMI SENS2 I -
E↓&L
- - Z O/L HDMI IN signal detect input
128 P152/AN152/ CFSEL0 O C - - - Z O/L Image resolution selection control terminal
129 P151/AN151/ CFSEL1 O C - - - Z O/L Image resolution selection control terminal
130 VSS VSS - - - - - - - GND
131 P150/AN150/ VIDEO POWER O C - - Ed Z O/L VIDEO POWER control terminal(ON:"H")
132 VCC VCC - - - - - - - +3.3V
133 P107/AN7 IP RST O C - - Ed Z O/L Reset for IP CONVERTER(FLI2310)
134 P106/AN6 TE RST O C - - Ed Z O/L Reset for COMPONENT FORMAT DETECTOR (TE8200PF)
135 P105/AN5 VD RSTZ1 O C - - Ed Z O/L Reset for VIDEO DECODER(ADV7403)
136 P104/AN4 Z1CERST O C - - Ed Z O/L Reset for COMPONENT ENCODER(ADV7320)
137 P103/AN3 Z1SVERST O C - - Ed Z O/L Reset for S/CVBS ENCODER(ADV7320)
138 P102/AN2 (G BDOWN) O C - - (-) Z O/L NC(VIDEO-GUI communication control terminal)
139 P101/AN1 (RST G) O C - - (-) Z O/L NC(VIDEO-GUI communication control terminal)
140 AVSS AVSS - - - - - - - Analog GND
141 P100/AN0 (ACK GIVO) O C - - (-) Z O/L NC(VIDEO-GUI communication control terminal)
142 VREF VREF - - - - - - - Standard power input +3.3V
143 AVCC AVCC - - - - - - - Analog power +3.3V
144 P97/ADTRG/RXD4 (GOVI) O C - - (-) Z O/L NC(VIDEO-GUI communication control terminal)
Pin Pin name Symbol I/O Type Det Op(Int.) Op(Ext.) Res stop Function
