ENGLISH
Specifi cations
Make detail settings for various parameters.
1
Press SYSTEM SETUP.
“System Setup” is displayed.
2
Press ENTER.
Three setup menu categories are displayed.
“1. Sp” : Speaker Setup
“2. In” : Input Setup
“3. Op” : Option Setup
• The cursor of the item number selected blinks.
• For details of the items to be set in each item, see “Menu Map”
(vpage 18).
3
Press o p to select the item you want to set, then
press ENTER.
The detailed setup menu for each item is displayed.
4
Press ui to select the item you want to change, then
press o p to change the setting.
5
Press ENTER or i to con rm the next settings.
Setup
2
1 . S p 2 . I n 3 . O p
4
Q
1 F r o n t : L a r g e
1
* S y s t e m S e t u p
Q
S p e a k e r S e t u p
3
[Selectable items]
Large Small
In lists of selectable items or adjustable ranges, the item
surrounded by a border is the default value.
uiop
ENTER
[AUDIO DELAY]
ENTER, op
uiSYSTEM SETUP
uiop
ENTER
SYSTEM SETUP
[TEST]
[Front]
[Rear]
Button located on both the main unit and the remote control
unit BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control unit [BUTTON]
Symbols used to indicate buttons in this manual
n To move to a setup item of another category
Press SYSTEM SETUP.
• Returns to the setup menu.
• Perform steps 3 and 4.
n To exit setup
Press SYSTEM SETUP while the setup menu is displayed.
• The display returns to normal.
System setup operation
The same operation is possible on the main unit or remote control
unit.
System Setup
Example of Display of Default
Values
