Denon AVR-786 - Parts List of Exploded View

72
AVR-1906 / AVR-786 / AVC-1620
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
BKE3 : U.S.A. & Canada model(Black) SRE3 : U.S.A. model (AVR-786)(Silver)
BKE2 : Europe model (Black) SRE2 : Europe model(Silver) E2A : Asia model EUT : Taiwan R.O.C. model
E1K : Korea model JP : Japan model
Ref. No. nsp Part No. Part Name Remarks Q'ty New
101 nsp 00D 963 0241 502 MAIN PCB ASSY BKE3,SRE3 1
101 nsp 00D 963 0242 103 MAIN PCB ASSY BKE2,SRE2,E2A 1
101 nsp 00D 963 0242 608 MAIN PCB ASSY EUT 1
101 nsp 00D 963 0243 005 MAIN PCB ASSY E1K 1
101 nsp 00D 963 0243 306 MAIN PCB ASSY JP 1
61 - MAIN PCB ASSY
61 - MAIN PCB ASSY
61 - MAIN PCB ASSY
61 - MAIN PCB ASSY
61 - MAIN PCB ASSY
54 - ENCODER PCB ASSY
53 - HEAD PHONE PCB ASSY
102 nsp 00D 963 0241 609 CPU/FRONT PCB ASSY BKE3,SRE3 1
102 nsp 00D 963 0242 200 CPU/FRONT PCB ASSY BKE2,SRE2,E2A 1
102 nsp 00D 963 0242 705 CPU/FRONT PCB ASSY EUT 1
102 nsp 00D 963 0243 102 CPU/FRONT PCB ASSY E1K 1
102 nsp 00D 963 0243 403 CPU/FRONT PCB ASSY JP 1
58 - FRONT PCB ASSY
58 - FRONT PCB ASSY
58 - FRONT PCB ASSY
63 - CPU PCB ASSY
63 - CPU PCB ASSY
63 - CPU PCB ASSY
63 - CPU PCB ASSY
63 - CPU PCB ASSY
55 - V.AUX PCB ASSY
56 - OPTICAL-IN PCB ASSY
52 - POWER-SW PCB ASSY
103 nsp 00D 963 0241 706 CNT PCB ASSY BKE3,SRE3 1
103 nsp 00D 963 0242 307 CNT PCB ASSY BKE2,SRE2,E2A 1
103 nsp 00D 963 0242 802 CNT PCB ASSY EUT 1
103 nsp 00D 963 0243 209 CNT PCB ASSY E1K 1
103 nsp 00D 963 0243 500 CNT PCB ASSY JP 1
62 - CNT PCB ASSY
62 - CNT PCB ASSY
59 - 2CH-AMP PCB ASSY
60 - PRE-AMP PCB ASSY
71 - OUTLET PCB ASSY
71 - OUTLET PCB ASSY
71 - OUTLET PCB ASSY
71 - OUTLET PCB ASSY
71 - OUTLET PCB ASSY
64 - EXT-IN PCB ASSY
64 - EXT-IN PCB ASSY
104 nsp 00D 963 0241 803 EXT-IN(E3) PCB ASSY BKE3,SRE3 1
64 - EXT-IN PCB ASSY
68 - COMP PCB ASSY
70 - VIDEO CNT PCB ASSY
69 - COMP CNT PCB ASSY
