• After adjusting using the test tones, adjust the channel levels either according to the playback sources or to suit your tastes, as (described)
below.
1
Select the speaker whose level you want
to adjust.
The channel switches as shown below each time the button
is pressed.
2
Adjust the level of the selected
speaker.
NOTE: Please make sure the “AUDIO” position of the slide
switch on the remote control unit.
Default setting of channel level is 0 dB.
The level of the selected speaker can be adjusted within
the range of +12 to –12 dB using the cursor buttons.
SW channel level can be turned off by decreasing one step
from -12 dB.
OFF ´ -12 dB ´ 12 dB
“SB” appears only when “POWER AMP ASSIGN” setting
is SURR. BACK mode.
