Connection 2 : Connection through the video output connector and speaker output connector
When “Assign Mode” in the menu is set to any of the following audio is output from speakers in ZONE2 or ZONE3. (v p. 232)
n
Assign Mode: 11.1ch + ZONE2
.
IN
VIDEO
VIDEO
COMPONENT VIDEO
YP
B PR
IN
wq wwq
(L) (R)
ZONE2
or
This unit
MAIN ZONE
ASSIGNABLE
HEIGHT3 HEIGHT3
VIDEO
MONITOR/ZONE3
ZONE2
(ASSIGNABLE)
COMPONENT VIDEO
MONITOR
Y
P
B/
C
B
PR/
C
R
z
1
n
Assign Mode: 11.1ch + ZONE3
.
IN
VIDEO
VIDEO
COMPONENT VIDEO
YP
B PR
IN
wq wwq
(L) (R)
z
1
z
2
ASSIGNABLE
HEIGHT3 HEIGHT3
VIDEO
MONITOR/ZONE3
ZONE2
(ASSIGNABLE)
COMPONENT VIDEO
MONITOR
Y
P
B/
C
B
PR/
C
R
ZONE3
or
This unit
MAIN ZONE
z1
Set “ZONE2” or “ZONE3” for “Analog Video Out” - “Component” in the menu to enable use of the MAIN ZONE component video output terminal for ZONE2 or ZONE3.
(v p. 212)
z2 Set “ZONE3” for “Analog Video Out” - “Video” in the menu to enable use of the MAIN ZONE video output terminal for ZONE3. (v p. 212)
