Denon AVR-S500BT Service Manual

FRONT
1
FRONT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1001 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
D1003 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
D1004 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT 1
D1005 90M-HD302450R DIODE,ZENER,1/2W,13V CVDZJ13BT 1
D1012 943176010090S L.E.D,(GREEN/RED5PI) CVDBLBJEGJ204L 1
Q1001 943219006820S T.R CVTKTC1027YT 1
Q1003,1004 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1005 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q1006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1008 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1009 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1011 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
RC101 943262100140S SENSOR,REMOTE(37.9KHz) CRVHM238RT12 1
RESISTOR GROUP
R1001 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1004 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1005,1006 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R1007 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R1008,1009 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R1010 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R1012-1015 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R1016,1017 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R1018,1019 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R1020 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R1021 nsp
RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1025,1026 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 2
R1030 nsp RES,CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1041,1042 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R1043 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1046 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1053 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R1057 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R1058,1059 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R1060,1061 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R1067 nsp RES,CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1068 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R1069 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1071 nsp RES,CHIP(1608/5%/5.6Kohm) S500BT CRJ10DJ562T 1
R1072 nsp RES,CHIP(1608/5%/3.3Kohm) S500BT CRJ10DJ332T 1
R1073 nsp RES,CHIP(1608/5%/2.7Kohm) S500BT CRJ10DJ272T 1
R1073 nsp RES,CHIP(1608/5%/1.5Kohm) X5100BT CRJ10DJ152T 1
R1074 nsp RES,CHIP(1608/5%/1.5Kohm) S500BT CRJ10DJ152T 1
R1074 nsp RES,CHIP(1608/5%/1Kohm) X5100BT CRJ10DJ102T 1
R1075 nsp RES,CHIP(1608/5%/1Kohm) S500BT CRJ10DJ102T 1
R1075 nsp RES,CHIP(1608/5%/0ohm) X5100BT CRJ10DJ0R0T 1
R1076 nsp RES,CHIP(1608/5%/5.6Kohm) S500BT CRJ10DJ562T 1
R1077 nsp RES,CHIP(1608/5%/3.3Kohm) S500BT CRJ10DJ332T 1
R1077 nsp RES,CHIP(1608/5%/1.5Kohm) X5100BT CRJ10DJ152T 1
R1078 nsp RES,CHIP(1608/5%/2.7Kohm) S500BT CRJ10DJ272T
1
R1078 nsp RES,CHIP(1608/5%/1Kohm) X5100BT CRJ10DJ102T 1
R1079 nsp RES,CHIP(1608/5%/1.5Kohm) S500BT CRJ10DJ152T 1
R1079 nsp RES,CHIP(1608/5%/0ohm) X5100BT CRJ10DJ0R0T 1
R1080 nsp RES,CHIP(1608/5%/1Kohm) S500BT CRJ10DJ102T 1
R1080 nsp RES,CHIP(1608/5%/0ohm) X5100BT CRJ10DJ0R0T 1
R1081 nsp RES,CHIP(1608/5%/5.6Kohm) S500BT CRJ10DJ562T 1
R1082 nsp RES,CHIP(1608/5%/3.3Kohm) S500BT CRJ10DJ332T 1
R1082 nsp RES,CHIP(1608/5%/2.7Kohm) X5100BT CRJ10DJ272T 1
R1083 nsp RES,CHIP(1608/5%/2.7Kohm) S500BT CRJ10DJ272T 1
R1083 nsp RES,CHIP(1608/5%/1.5Kohm) X5100BT CRJ10DJ152T 1
R1084 nsp RES,CHIP(1608/5%/1.5Kohm) S500BT CRJ10DJ152T 1
R1084 nsp RES,CHIP(1608/5%/1Kohm) X5100BT CRJ10DJ102T 1
R1085 nsp RES,CHIP(1608/5%/1Kohm) S500BT CRJ10DJ102T 1
R1085 nsp RES,CHIP(1608/5%/1Kohm) X5100BT CRJ10DJ102T 1
R1413,1414 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R1415,1416 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
VR101 943671010330S ENCODER(16MM,24PULSES),W/CLICK CSR2A055Z 1
VR102 943671101000D ENCODER(16MM,12PULSES) Operatingtemperaturerange:-10'Cto+70'C CSR2A060Z 1 *
CAPACIITORS GROUP
C1002 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C1003 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C1004 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 1
C1005 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C1006 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1007 nsp
CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C1009 nsp CAP,CHIP(2012,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUC1H104KCS 1
C1010 nsp CAP,ELECT(16V/10uF)-S CCEA1CKS100T 1
C1011 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C1013,1014 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 2
C1015 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 1
C1016 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS 1
C1017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C1019 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C1020 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C1038 nsp CAP,ELECT(16V/47uF)-S CCEA1CKS470T 1
C1039 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 1
C1054,1055 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C1065 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1066 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C1067 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1068 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C1071,1072 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H681JAS 2
C1073 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C1076,1077 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 2
