Denon AVR-S500BT - Page 111

FRONT
2
REF No. Part No. Part Name Remarks Q'ty New Ver
C1081 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C1424 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C1425,1426 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 2
OTHER PARTS GROUP
CN102 nsp WAFER/ANGLE/2.5mm/07P CJP07GB03ZY 1
CN103 nsp LOCK-WAFER/ANGLE/2MMPITCH/3PIN CJP03GJ288ZY 1
CN104 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY 1
BK101,102 nsp BRACKET,FIP CMD1A572-V1 2
BN101 nsp WIREASS'YB'D-B'DIN(9P,2MM,80MM,#28) 80'C1007#28BLK/(RED)Borad_in-Borad_in CWB1A009080CC 1
BN12B1 nsp WAFER,FFC1.25mm,ANGLE CJP27GB286ZN 1
BN131 nsp WIREASS'YLocking(YH)(3P,2MM,50MM,#28) 80'C1007#28BLK/(RED)Locking-Borad_in CWB1A003050HC 1
! F1001 943652000620S FUSE(372Series/100mA/TR5) CBA2D0100A3EYT 1
FL101 943172100150S V.F.D(FUTABA,18-BT-02GINK) CFL18BT021GINK 1
JK104 90M-YT004500R JACK,PHONES(6.35mm,SILVER) CJJ2E026Z 1
L1001 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1010-1013 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 4
L1402-1404 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 3
SW101 00D9430004402 SW,TACT CST1A012ZT 1
SW102,103 00D9430004402 SW,TACT S500BT CST1A012ZT 2
SW104-106 00D9430004402 SW,TACT CST1A012ZT 3
SW107,108 00D9430004402 SW,TACT S500BT CST1A012ZT 2
SW109,111 00D9430004402 SW,TACT CST1A012ZT 3
SW112-114 00D9430004402 SW,TACT S500BT CST1A012ZT 3
SW115-118 00D9430004402 SW,TACT CST1A012ZT 4
SW119 00D9430004402 SW,TACT S500BT CST1A012ZT 1
