Denon AVR-S500BT Service Manual

20
1. Initialization Mode
1.1. Operations
Hold down buttons below at the same time and press the power button to turn on the power.
"SOUND MODE
1
", "PRESET +" (AVR-S500BT)
"PRESET +", "TUNE +" (AVR-X510BT)
Release the buttons after conrming that the display ashes in intervals of approximately 1 second.
1.2. Actions
Initialize this unit.
Note:Settings for the tuner step are not initialized.
2. Version Display Mode
2.1. Operations
Hold down buttons below at the same time and press the power button to turn on the power.
"PRESET +", "TUNE -" (AVR-S500BT)
"TUNE +", "DIMMER" (AVR-X510BT)
Press the button "STATUS" to display the versions.
2.2. Actions
Press the "STATUS" button to display the versions in the following order.
Error information(See 2.4. Error display) →
q
Model destination information →
w
Main-µcom version →
e
Main IAP →
r
DSP version →
t
OSD version
→
y
USB version
→ Nomal display
When an error has occurred in this unit, the error information is displayed initially when entering this mode. (5 seconds)
Display State
q
Model destination information
AVR-S500BT
E3 model
A V R - S 5 0 0 E 3
AVR-X510BT E1 model
A V R - X 5 1 0 E 1
AVR-X510BT E1C model
A V R - X 5 1 0 E 1 C
AVR-S500BT E1C model
A V R - S 5 0 0 E 1 C
w
Main-µcom version
M a i n . * * * * - V * . * *
e
Main IAP
M a i n I A P V * * . * *
r
DSP version
D S P . * . * . *
t
OSD version
O S D : * * . * *
y
USB version
U S B . * * . * * . * *
2.3. Canceling the mode:
Press the
X
button to turn the power off.
2.4. Error display
See the following table for each "Error information" display and its contents (status).
Condition - State
DSP NG When DSP boot, executing DSP reset makes to becomes error.
D S P E R R O R 0 1
DSP OK (No error display, version display only)
