Denon AVR-S500BT - Page 116

POWER
7
POWER PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D3001-3004 00D9630328409 CVD1N4007ST DIODE,RECTIFIER,AXIAL CVD1N4007ST 4
D3103,3104 00D9430182609 CVD1SS133MT DIODE,SWITCHING CVD1SS133MT 2
D6001-6008 00D9630328409 CVD1N4007ST DIODE,RECTIFIER,AXIAL CVD1N4007ST 8
D6009 00D9430182609 CVD1SS133MT DIODE,SWITCHING CVD1SS133MT 1
D6012 00D9630328409 CVD1N4007ST DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
D6013 943204500310S CVDRBQ30T65A DIODE,SchottkyBattier(TO220FN) 65V,30A CVDRBQ30T65A 1
IC301 943232100370S CVIKIA7812BPI I.C,REGULATOR(+12V,TO220) CVIKIA7812BPI 1
IC302 00D9430183909 HVIKIA7912PI I.C,REGULATOR HVIKIA7912PI 1
IC305 943231010390S CVIKIA7805BPI I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
! IC601 231010091708S CVITOP258MG I.C,OFF-LINEPOWERSWITCH CVITOP258MG 1
! IC602 963239010480S CVIPC123Y22FZ0F I.C,PHOTOCOUPLER CVIPC123Y22FZ0F 1
IC603 212050010508S CVIKIA2431AP I.C,SHUNTREGULATOR(TO-92) CVIKIA2431AP 1
Q6002 943229500110S CVTINK0010AC1 F.E.T,INK0010AC1(N-CH,SC-59,MOSFET,ISAHAYA) CVTINK0010AC1 1
Q6003 943214500020S CVT2SC3052 T.R,2SC3052 CVT2SC3052 1
ZD608-610 00D2760762958 CVDZJ39BT DIODE,ZENER,1/2W,39V E3 CVDZJ39BT 3
ZD611-618 963202010440S CVDZJ22BT DIODE,ZENER,1/2W,22V CVDZJ22BT 8
ZD619 90M-HD302360R CVDZJ6.8BT DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
ZD620 00D2760762958 CVDZJ39BT DIODE,ZENER,1/2W,39V CVDZJ39BT 1
ZD621 00D9430196306 CVDZJ7.5BT DIODE,ZENER,1/2W,7.5V E3 CVDZJ7.5BT 1
ZD621 943202000940S CVDZJ16BT DIODE,ZENER,1/2W,16V E1, E1C CVDZJ16BT 1
RESISTOR GROUP
R6004 nsp CRD20TJ334T RES,CARBON(1/5W,330Kohm,J) CRD20TJ334T 1
R6006 nsp CRJ10DJ105T RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R6008,6009 nsp CRD20TJ225T RES,CARBON(1/5W,2.2Mohm,J) E3 CRD20TJ225T 2
R6010 nsp CRD20TJ105T RES,CARBON(1/5W,1Mohm,J) E3 CRD20TJ105T 1
R6010 nsp CRD20TJ105T RES,CARBON(1/5W,1Mohm,J) E3 CRD20TJ105T 1
R6011 nsp CRJ10DJ100T RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R6012 nsp CRJ10DJ274T RES,CHIP(1608/5%/270Kohm) E3 CRJ10DJ274T 1
R6012 nsp CRJ10DJ563T RES,CHIP(1608/5%/56Kohm) E1, E1C CRJ10DJ563T 1
R6013 nsp CRJ10DJ153T RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R6014 nsp CRJ10DJ102T RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6015 nsp CRD20TJ6R8T RES,CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1
R6016 nsp CRD20TJ560T RES,CARBON(1/5W,56ohm,J) CRD20TJ560T 1
R6017 nsp CRD20TJ332T RES,CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R6018 nsp CRD20TJ562T RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R6019 nsp CRJ10DF2202T RES,CHIP(1608/1%/22Kohm) CRJ10DF2202T 1
R6022 nsp CRJ10DF6801T RES,CHIP(1608/1%/6.8Kohm) CRJ10DF6801T 1
R6024 nsp CRJ10DJ103T RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6025 nsp CRJ10DJ472T RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6027-6030 nsp CRJ18AJ825T RES,CHIP(2012/5%/8.2Mohm) 1/8W,2012SIZE CRJ18AJ825T 4
R6031-6033 nsp CRJ18AJ105T RES,CHIP(2012/5%/1Mohm) CRJ18AJ105T 3
! RY601 963682010370S CSL1C006ZE RELAY,HL31-1AT-5H,DC5V,1C1P CSL1C006ZE 1
CAPACIITORS GROUP
C3005 00MOF15104040 CCME2A104JXT CAP,METAL-FILM(100V/0.1uF) CCME2A104JXT 1
C3006 943134010620S CCEA1EH472E CAP,ELECT(25V/4700uF) CCEA1EH472E 1
C3007 00MOA33802520 CCEA1EH332E CAP,ELECT(25V/3300uF) CCEA1EH332E 1
C3008 943134502350S CCEA1HH471E CAP,ELECT(50V/470uF) CCEA1HH471E 1
C3012,3013 943134502350S CCEA1HH471E CAP,ELECT(50V/470uF) CCEA1HH471E 2
! C6001-6003 963132011940S CCKDKY103MFM CAP,CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM 3
C6004 943134501590S CCET200NHA101ES CAP,ELECT(200V/100uF),105'C E3 CCET200NHA101ES 1
C6004 963134010200S CCET400NHA101ES CAP,ELECT(400V/100UF,18X40,NHA) E1, E1C CCET400NHA101ES 1
C6005 nsp CCUS1H473KCS CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H473KCS 1
C6006 nsp CCUS1H103KCS CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C6007 nsp CCUS1H104KCS CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6008 00D9430175108 CCEA1HNXA100TS CAP,ELECT(50V/10uF),105'C CCEA1HNXA100TS 1
C6009 nsp CCUS1H104KCS CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6011 963132010120S CCKDDEH102KCM CAP,CERAMIC(DC1KV/1000pF) CCKDDEH102KCM 1
C6012 nsp CCUS1H104KCS CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6013 00MOA47602520 CCEA1ENXA470TS CAP,ELECT(25V/47uF),105'C CCEA1ENXA470TS 1
C6014 nsp CCUS1H104KCS CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6015 nsp CCUS0J475KCS CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 1
C6018,6019 963134010220S CCEA0JNXA562ES CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES 2
C6020 nsp CCUS1H104KCS CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
! C6023 963132011930S CCKDKX222MEM CAP,CERAMIC(X1/Y1,2200P,AC250V) CCKDKX222MEM 1
C6024 nsp CCUS1H104KCS CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6026 943132100510S CCUP3A470JA CAP,CHIP(3216,1KV/47pF,X7R) 1KV,47pF
S700/X110共通
CCUP3A470JA 1 *
OTHER PARTS GROUP
CN302 nsp CJP05GA01ZY WAFER/STRAIGHT/2.5mm/5P CJP05GA01ZY 1
CN601 nsp CJP02KA060ZY WAFER,2P,3.96mm CJP02KA060ZY 1
CN602 nsp CJP02GA89ZY WAFER,2P,7.92mm CJP02GA89ZY 1
! CX601 943139500020S HCQF2E104KZE CAP,POLYPROPYLENEFILM HCQF2E104KZE 1
! CY601,602 963134011730S CCKDKX471KBM CAP,CERAMIC(X1/Y1,470P,AC250V) CCKDKX471KBM 2
BK301,302 nsp CMD1A569-V1 BRACKET,PCB CMD1A569-V1 2
BK303 nsp CMD1A387-V1 BRACKET,PCB CMD1A387-V1 1
BK601,602 nsp CMD1A834 BRACKET,PCBM3 CMD1A834 2
BK603 nsp CMD1A629 BRACKET,PCB CMD1A629 1
BN301 nsp CWB1C0071303D WIREASS'YLocking(YH)(7P,2.5MM,130MM,#24) 80'C1007#24BLK/(RED)Locking-Borad_in CWB1C0071303D 1
BN601 nsp CWB1D0052203D WIREASS'YLocking(YH)(5P,2.5MM,220MM,#22) 80'C1007#22BLK/(RED)Locking-Borad_in CWB1D0052203D 1
F3003,3004 943652500510D CBA2J1250TLEBT FUSE(932Series,250V/1.25A) 932Series,250V/1.25A,Sub-miniatureFuse CBA2J1250TLEBT 2 *
F6001,6002 nsp KJCFC5S HOLDER,FUSE KJCFC5S 2
! F6001 963652010510S FUSE(S506Series,250V,2A) E3 CBA2C2000TLEC 1
! F6001 963652010500S FUSE(S506Series,250V,1.6A) E1, E1C CBA2C1600TLEC 1
! LF602 963111010230S CLZ9Z126Z LINEFILTER,27mH E3 CLZ9Z126Z 1
! LF602 943111100410S CLZ9Z133Z LINEFILTER,50mH E1, E1C CLZ9Z133Z 1
! T6001 943102100350S CLT9Z093ZE TRANS,SWITCHING TT3-ASST00204 CLT9Z093ZE 1
