DIGTAL
8
DIGTAL PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D7105,7106 943202500730S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z5V1H 2
D7501-7503 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 3
D7601,7602 00D9430196306 DIODE,ZENER,1/2W,7.5V CVDZJ7.5BT 2
D7605-7607 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 3
D7608 943202500720S DIODE,ZENER(3.6V/0.5W,SOD-123) CVDMM1Z3V6H 1
IC711
－
I.C,FLASH32BITMCU(LQFP-144P) ARM32bitMCU1MBFlash CVISTM32F101ZG 1
IC711┗
943243102140D I.C,MAINMCU(AVR-S500BT_X510BT) CVIANAM1891AV 1 *
IC712 943246010440S I.C,EEPROM(32Kbit)ST CVIM24C32WMN6TP 1
IC721 943236012460S I.C,HDMITransceiver(LQFP-144P) CVIADV7623BSTZ 1
IC722
－
I.C,SERIALFLASH(32M) CVIMX25L3206EM2I-12G 1
IC722┗
943248102640D I.C,OSD ROM (AVR-S500BT_X510BT) CVIANAM1892AV 1 *
IC731 963236101810S I.C,HDMI2.0Transceiver(HQFP-144P) 4K2K/60Hz,RX4,TX2 CVIMN8647781 1 *
IC741 943245010410S EOLitemI.C,DSP(CIRRUSLOGIC) CVICS497024CVZ 1
IC742
－
I.C,SERIALFLASH(8M) CVIMX25L8006EM2I-12G 1
IC742┗
943248102650D I.C,DSP ROM (AVR-S500BT_X510BT) CVIANAM1893AV 1 *
IC743 943236101210S I.C,16MBSDRAM(TSOP-50P) CVIM12L16161A5TG2Q 1
IC744 90M-HC110090R I.C,CODEC+DIR(CIRRUSLOGIC) HVICS42528-CQ 1
IC745-747 00D2623198902 I.C,QUAD2-CHANNELMUX(TSSOP-16) HVITC74VHC157FT 3
IC751-753 943239101070S I.C,DC-DCCONVERTER(3A,QFNT&R-24P) DC-DCConverter,3.2MHz,WithIntegratedInductor CVIEN5339QI 3
IC755 943239100730S I.C,SYSTEMRESET(4.8V,SOT-25A) SystemResetIC,SOT-25A CVIPST8448NR_A 1
IC756 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC761 943235100520S I.C,INPUTWITH8CHVOLUME(52PLQFP) CVINJU72340AFH3 1
IC762-764 943232100380S I.C,DUALOPAMP(SOP-8P) LowTHD0.0005%,FORIMPROVINGTHETONECONTROL CVINJM8080G 3
IC766,767 00MHC10172090 I.C,OPAMP HVINJM2115MTE1 2
Q7105-7108 943214500020S T.R,2SC3052 CVT2SC3052 4
Q7109 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7110 943214500020S T.R,2SC3052 CVT2SC3052 1
Q7201-7206 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 6
Q7301-7304 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 4
Q7501 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7502,7503 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 2
Q7504,7505 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 2
Q7506 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7507 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7508 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7509 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7510 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7512 943214500020S T.R,2SC3052 CVT2SC3052 1
Q7513 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7514 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7517 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7518 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7519 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7520 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7521 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7522 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q7610 943214500030S T.R,MUTE CVTINC2001AC1 1
Q7612 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q7613 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7614 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
RESISTOR GROUP
R7101 nsp RES,CHIP(1005/5%/470Kohm) CRJ06IJ474T 1
R7102 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7103 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7104 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R7107 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7108 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7113 nsp RES,CHIP(1608/5%/4.7Kohm) E3 CRJ10DJ472T 1
R7113 nsp RES,CHIP(1608/5%/10Kohm) E1C CRJ10DJ103T 1
R7114 nsp RES,CHIP(1608/5%/10Kohm)
S500BTE3, X510BTE1,
X510BTE1C
CRJ10DJ103T 1
R7115,7116 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 2
R7127 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7129 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7136,7137 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 2
R7138 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7139 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7143,7144 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 2
R7145 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R7147,7148 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 2
R7149-7151 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 3
R7152 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7153,7154 nsp RES,CHIP(1005/5%/2.7Kohm) CRJ06IJ272T 2
R7155-7157 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 3
R7159 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7160 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7162 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7163-7165 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 3
R7166 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R7167 nsp RES,CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R7168 nsp RES,CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R7171 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7172 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7173-7177 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 5
R7188,7189 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7190 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7191 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7192 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7201 nsp RES,CHIP(1608/1%/1.6Kohm) CRJ10DF1601T 1
R7202 nsp RES,CHIP(1608/1%/2Kohm) CRJ10DF2001T 1
R7203,7204 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R7206 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7208 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7210-7212 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 3
R7213-7216 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 4
R7218-7221 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 4
R7222 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7224 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7228 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7231 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7232-7235 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 4
R7236,7237 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 2
R7238-7241 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
R7242-7245 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 4
R7246 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7247 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7248 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7250 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7251 nsp RES,CHIP(1608/5%/390Kohm) CRJ10DJ394T 1
R7252,7253 nsp RES,CHIP(1005/1%/1Kohm) CRJ06IF1001T 2
