Denon avr-s720w Service Manual

FRONT
FRONT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1001 943203500730S DIODE,RECTIFIER,AXIAL CVD1N4007SL 1 *
D1002 00D9430182609 DIODE,SWITCHING E3 CVD1SS133MT 1
D1003 943202501110S DIODE,ZENER,1/2W,6.8V CVDZJ6V8BL 1 *
D1004 nsp EOLitemWIRE,COPPER(D0.6) C3A206 0.02
D1005 943202501120S DIODE,ZENER,1/2W,39V CVDZJ39BL 1 *
D1008 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1 1
D1009 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1 1
D1010 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1 1
D1011 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1 1
D1012 943176010090S L.E.D,(GREEN/RED5PI) S720, E2, E1C, JP CVDBLBJEGJ204L 1
D1012 963263100960S LED,WHITE/RED E3 CVDPVBWR5A2M 1
D1019 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D1020 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D1401 943202501130S DIODE,ZENER,1/2W,5.1V CVDZJ5V1BL 1 *
D1402 943202501130S DIODE,ZENER,1/2W,5.1V CVDZJ5V1BL 1 *
D1403 943202501130S DIODE,ZENER,1/2W,5.1V CVDZJ5V1BL 1 *
D1404 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D1405 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
IC101 943232100540S I.C,DUALOPAMP(SOP-8P) CVINJM4580CG 1 *
Q1001 943219006820S T.R CVTKTC1027YT 1
Q1002 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1003 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1004 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1005 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q1006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1007 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1008 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1009 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1011 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1013 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1014 943219006820S T.R CVTKTC1027YT 1
Q1015 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1016 943214500020S T.R,2SC3052 CVT2SC3052 1
RESISTOR GROUP
R1001 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1004 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1005 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R1006 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R1007 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R1008 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R1009 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R1010 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R1011 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1012 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1013 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1014 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1015 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1016 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1017 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1018 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1019 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1020 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R1021 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1022 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1023 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R1025 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R1026 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R1027 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1030 nsp RES,CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1040 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1041 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 1
R1042 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 1
R1043 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1053 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R1057 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R1058 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1059 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1060 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1061 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1067 nsp RES,CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1071 nsp RES,CHIP(1608/5%/330ohm) S720 CRJ10DJ331T 1
R1072 nsp RES,CHIP(1608/5%/220ohm) S720 CRJ10DJ221T 1
R1073 nsp RES,CHIP(1608/5%/180ohm) S720 CRJ10DJ181T 1
R1073 nsp RES,CHIP(1608/5%/150ohm) E3, E2, E1C, JP CRJ10DJ151T 1
R1074 nsp RES,CHIP(1608/5%/150ohm) S720 CRJ10DJ151T 1
R1074 nsp RES,CHIP(1608/5%/100ohm) E3, E2, E1C, JP CRJ10DJ101T 1
R1075 nsp RES,CHIP(1608/5%/100ohm) S720 CRJ10DJ101T 1
R1075 nsp RES,CHIP(1608/5%/0ohm) E3, E2, E1C, JP CRJ10DJ0R0T 1
R1076 nsp RES,CHIP(1608/5%/330ohm) S720 CRJ10DJ331T 1
R1077 nsp RES,CHIP(1608/5%/220ohm) S720 CRJ10DJ221T 1
R1077 nsp RES,CHIP(1608/5%/150ohm) E3, E2, E1C, JP CRJ10DJ151T 1
R1078 nsp RES,CHIP(1608/5%/180ohm) S720 CRJ10DJ181T 1
R1078 nsp RES,CHIP(1608/5%/100ohm) E3, E2, E1C, JP CRJ10DJ101T 1
R1079 nsp RES,CHIP(1608/5%/150ohm) S720 CRJ10DJ151T 1
R1079 nsp RES,CHIP(1608/5%/0ohm) E3, E2, E1C, JP CRJ10DJ0R0T 1
R1080 nsp RES,CHIP(1608/5%/100ohm) S720 CRJ10DJ101T 1
R1080 nsp RES,CHIP(1608/5%/0ohm) E3, E2, E1C, JP CRJ10DJ0R0T 1
R1081 nsp RES,CHIP(1608/5%/330ohm) S720 CRJ10DJ331T 1
R1082 nsp RES,CHIP(1608/5%/220ohm) S720 CRJ10DJ221T 1
R1082 nsp RES,CHIP(1608/5%/180ohm) E3, E2, E1C, JP CRJ10DJ181T 1
R1083 nsp RES,CHIP(1608/5%/180ohm) S720 CRJ10DJ181T 1
R1083 nsp RES,CHIP(1608/5%/150ohm) E3, E2, E1C, JP CRJ10DJ151T 1
R1084 nsp RES,CHIP(1608/5%/150ohm) S720 CRJ10DJ151T 1
R1084 nsp RES,CHIP(1608/5%/100ohm) E3, E2, E1C, JP CRJ10DJ101T 1
R1085 nsp RES,CHIP(1608/5%/100ohm) S720 CRJ10DJ101T 1
R1085 nsp RES,CHIP(1608/5%/0ohm) E3, E2, E1C, JP CRJ10DJ0R0T 1
R1401 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1402 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1403 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1404 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1405 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1406 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1407 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R1408 nsp RES,CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
1

Denon avr-s720w Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-Through	Yes
HDR Support	Yes
3D Pass-Through	Yes
HDMI Version	2.0a
HDCP Version	2.2
AirPlay	Yes
Built-in HEOS	No
Phono Input	No
Ethernet Port	Yes
Dimensions (W x H x D)	17.1 x 6.6 x 13.3 inches
Power Output per Channel	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
USB Port	Yes
