Denon avr-s720w Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R7729 nsp RES,CHIP(1608/5%/680ohm) CRJ10DJ681T 1
R7730 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7731 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7738 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7739 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7751 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7752 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7753 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7754 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7755 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7756 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7757 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7758 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7759 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7760 nsp RES,CHIP(1608/5%/91ohm) CRJ10DJ910T 1
R7761 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7762 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7763 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7764 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7765 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7766 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7767 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7768 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7769 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7770 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7771 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7772 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7773 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7774 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7775 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7801 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7802 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7803 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7804 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7805 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7806 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7807 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7809 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7810 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7811 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7812 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R7813 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R7814 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7815 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7818 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7821 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7822 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7823 nsp RES,CHIP(1608/5%/20Kohm) CRJ10DJ203T 1
R7824 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7826 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R7827 nsp RES,CHIP(1608/5%/3.3Kohm)
CRJ10DJ332T 1
R7829 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R7832 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R7833 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7835 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7836 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7837 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7838 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7839 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7840 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7841 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7842 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7843 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7844 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7846 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7847 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7848 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7849 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7850 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7855 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7856 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7857 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7858 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7860 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7861 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7862 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7863 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7864 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7865 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7901 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R7902 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7903 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7904 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7907 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7908 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7911 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7912 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7913 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7914 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7915 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7916 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7917 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7918 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7919 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7921 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7922 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7923 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7924 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7925 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7926 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7927 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7928 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7929 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7931 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7932 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7933 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7934 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7935 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7936 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7937 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7938 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7939 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7941 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7942 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7943 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7944 nsp RES,CHIP(1608/0.5%/39Kohm) CRJ06DD393TP 1
R7945 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
17

Denon avr-s720w Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-Through	Yes
HDR Support	Yes
3D Pass-Through	Yes
HDMI Version	2.0a
HDCP Version	2.2
AirPlay	Yes
Built-in HEOS	No
Phono Input	No
Ethernet Port	Yes
Dimensions (W x H x D)	17.1 x 6.6 x 13.3 inches
Power Output per Channel	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
USB Port	Yes
