Denon avr-s720w Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R7946 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R7947 nsp RES,CHIP(1608/0.5%/39Kohm) CRJ06DD393TP 1
R7948 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R7949 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7951 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7952 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7953 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7954 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7955 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7956 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7957 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7958 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7959 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7961 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7962 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7963 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7964 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7965 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7966 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7967 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7968 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7969 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7971 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7972 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7973 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7974 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7975 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7976 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7977 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7978 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7979 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7981 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7982 nsp RES,CHIP(1608/0.5%/15Kohm) CRJ06DD153TP 1
R7983 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7984 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7985 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7986 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7987 nsp RES,CHIP(1608/0.5%/12Kohm) CRJ06DD123TP 1
R7988 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7989 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8001 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8002 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R8003 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R8004 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R8005 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R8006 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8010 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8011 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8013 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8015 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R8016 nsp RES,CHIP(1005/5%/33ohm)
CRJ06IJ330T 1
R8017 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R8019 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R8020 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R8021 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8022 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8026 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8027 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8028 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R8034 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R8035 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8036 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8037 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8038 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R8040 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R8041 nsp RES,CHIP(1005/5%/10ohm) CRJ06IJ100T 1
R8042 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8043 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8044 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8045 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8055 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8057 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8058 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8060 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8061 nsp RES,CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R8062 nsp RES,CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R8063 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8064 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8075 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R8201 nsp RES,CHIP(1608/5%/270ohm) CRJ10DJ271T 1
R8202 nsp RES,CHIP(1608/5%/270ohm) CRJ10DJ271T 1
R8203 nsp RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R8204 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8205 nsp RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R8206 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8207 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8208 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R8209 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8213 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8214 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8215 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R8216 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R8217 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8218 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8219 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R8220 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R8221 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8222 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8223 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8224 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8225 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8226 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8227 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8228 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8229 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8230 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8231 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R8236 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8237 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
R8238 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
R8239 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
R8240 nsp RES,M-OXIDEFILM(1W/150ohm) CRG1SANJ151RT 1
R8241 nsp RES,M-OXIDEFILM(1W/150ohm) CRG1SANJ151RT 1
R8242 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8243 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8244 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8245 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
18

Denon avr-s720w Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-Through	Yes
HDR Support	Yes
3D Pass-Through	Yes
HDMI Version	2.0a
HDCP Version	2.2
AirPlay	Yes
Built-in HEOS	No
Phono Input	No
Ethernet Port	Yes
Dimensions (W x H x D)	17.1 x 6.6 x 13.3 inches
Power Output per Channel	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
USB Port	Yes
