TPS563200 (DIGITAL_DIGITAL SUPPLY : IC741~745, 747)
Terminal Functions
PIN
DESCRIPTION
NAME NUMBER
GND 1
Ground pin Source terminal of low-side power NFET as well as the ground ter-
minal for controller circuit. Connect sensitive VFB to this GND at a single point.
SW 2 Switch node connection between high-side NFET and low-side NFET.
VIN 3 Input voltage supply pin. The drain terminal of high-side power NFET.
VFB 4
Converter feedback input. Connect to output voltage with feedback resistor
divider.
EN 5 Enable input control. Active high and must be pulled up to enable the device.
VBST 6
Supply input for the high-side NFET gate drive circuit. Connect a 0.1 μ F ca-
pacitor between VBST and SW pins.
Block diagram
SW
VBST
VFB
GND
2
3
1
EN
4
6
5
VIN
TPS562200, TPS563200
DDC (SOT) Package
Top View
2 SW
ZC
XCON
PWM
Control Logic
+
+
+
UVP
OVP
3 VIN
Ton
One-Shot
6
VBST
+
4
VFB
OCL
+
+
Soft Start
5EN
HS
LS
1 GND
SS
Voltage
Reference
Ref
Hiccup
V
UVP
V
OVP
OCL
threshold
Regulator
UVLO
VREG5
VREG5
TSD
R5F56108VNFP (DIGITAL_MCU : IC751)
R5F56108VNFP Terminal Functions
Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
1
P04/IRQ12-A/
TMCI3/TxD4/TDI
TDI/TXD MITSUBI-
SHI/NC(NORMRAL)
I/O/I M3VPu -/-/I -/-/I I
E20 Emulator control pin/Mitsubishi writter control
pin/When normal operating mode,set to input.
2
P03/IRQ11-A/
TMRI3/SCK4/TMS
TMS/NC(NORMRAL) I/I M3VPu -/I -/I I
E20 Emulator control pin/When normal operating
mode,set to input.
3 P67/DA1 HIN SELA O L L L HDMI +5V selector (TC4051) control pin
4 P66/DA0 HIN SELB O L L L HDMI +5V selector (TC4051) control pin
5 AVSS AVSS - - - - Ground pin
6
P02/IRQ10-A/
TMO2/SCK6/TRST#
TRST#/
NC(NORMRAL)
I/I Pd I/I I/I I
E20 Emulator control pin/When normal operating
mode is set to input.
7
P01/IRQ9-A/TMCI2/
RxD6
RXD MI232O I M3VPu I I I
External data input port (for AMX/FW update via
232C)　:Connector is FFC
8
P00/IRQ8-A/TMRI2/
TxD6
TXD MO232I O L L L
External data output port (for AMX/FW update via
232C) :Connector is FFC
9 P65/IRQ15-A POWER KEY I M3VPu I I I
Detect Power switch (Release from Wait Mode,Set
to interrupt)
10 EMLE EMLE I Pd - - -
E20 Emulator control pin (On chip Emulator is
used,this pin should be High. Not used,it should be
Low)
11 WDTOVF#/TDO TDO/WDTOVF# O/O - - - E20 Emulator control pin
12 VSS VSS I - - - Ground pin
13 MDE MDE I Pd - - -
Pins for setting the operating mode (Little
Edian:MDE=Low)
14 VCL VCL I - - - Smoothing capacitor connection pin
RX610 GROUP
PLQP0144KA-A
（144pin LQFP）
(Top View)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
108
107
106
105
104
103
102
101
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
PE0/D8
PD6/D6
PD5/D5
PD4/D4
P64/CS4#-B
P63/CS3#-A/CS7#-A
P62/CS2#-A/CS6#-A
P61/CS1#/CS2#-B/CS5#-A/CS6#-B/CS7#-B
P60/CS0#/CS4#-A/CS5#-B
PD3/D3
PD2/D2
PD1/D
1
PD0/D0
P96/AN14
P95/AN13
P94/AN12
P93/AN11
P92/AN10
P91/AN9
VSS
P90/AN8
VCC
P47/AN7/IRQ15-B
P46/AN6/IRQ14-B
P45/AN5/IRQ13-B
P44/AN4/IRQ12-B
P43/AN3/IRQ11-B
P42/AN2/IRQ10-B
P41/AN1/IRQ9-B
VREFL
P40/AN0/IRQ8-B
VREFH
P05/TMO3/RxD4/IRQ13-A/TCK
PD7/D7
P97/AN15
AVCC
PC4/A20
PC6/A22/RxD5/CS6#-D
PC7/A23/TxD5/CS4#-D/CS7#-D
P75
P76/IRQ14-A
P77
P50/WR0#/WR#
P51/WR1#/BC1#
P52/RD#
P53/BCLK
P80
P81/TRSYNC
VCC
VSS
P83
P54/TRDATA0
P55/TRDATA1
P56/TRDATA2
P57/WAIT#/TRDATA3
P84
P35/PO13/TIOCA1/TIOCB1/TCLKC-A
P36/PO14/TIOCA2
P37/PO15/TIOCA2/TIOCB2/TCLKD-A
P10/IRQ0-B
P11/SCK2/IRQ1-B
P12/RxD2/IRQ2-B
P1
3/TxD2/ADTRG0#/IRQ3-B
P14/TCLKA-B/SDA1/IRQ4-B
P15/TCLKB-B/SCK3/SCL1/IRQ5-B
PLLVSS
P16/TCLKC-B/RxD3/SDA0/IRQ6-B
PLLVCC
P20/PO0/TIOCA3/TIOCB3/TMRI0/TxD0
PC5/A21/SCK5/CS5#-D
P82/TRCLK
P17/TCLKD-B/TxD3/SCL0/ADTRG1#/IRQ7-
PE1/D9
PE3/D11
PE4/D12
PE5/D13/IRQ5-A
PE6/D14/IRQ6-A
PE7/D15/IRQ7-A
PA0/A0/BC0#/PO16/TIOCA6
PA1/A1/PO17/TIOCA6/TIOCB6
PA2/A2/PO18/TIOCC6/TCLKE
PA3/A3/PO19/TIOCC6/TIOCD6/TCLKF
PA4/A4/PO20/TIOCA7
PA5/A5/PO21/TIOCA7/TIOCB7/TCLKG
PA6/A6/PO22/TIOCA8
VSS
PB0/A8/PO24/TIOCA9
VCC
P70/CS3#-B/ADTRG2#
P71/CS4#-C/CS5#-C/CS6#-C/CS7#-C
P72
P73
P74/ADTRG3#
PB1/A9/PO25/TIOCA9/TIOCB9
PB2/A10/PO26/TIOCC9
PB3/A11/PO27/TIOCC9/TIOCD9
PB4/A12/PO28/TIOCA10
PB5/A13/PO29/TIOCA10/TIOCB10
PB6/A14/PO30/TIOCA11
PB7/A15/PO31/TIOCA11/TIOCB11
PC0/A16
P
C1/A17
VSS
PC2/A18
PC3/A19
PE2/D10
PA7/A7/PO23/TIOCA8/TIOCB8/TCLKH
VCC
P04/TMCI3/TxD4/IRQ12-A/TDI
P67/DA1
P66/DA0
AVSS
P02/TMO2/SCK6/IRQ10-A/TRST#
P01/TMCI2/RxD6/IRQ9-A
P00/TMRI2/TxD6/IRQ8-A
P65/IRQ15-A
EMLE
WDTOVF#/TDO
VSS
MDE
VCL
MD0
P86
P85
RES#
XTAL
VSS
EXTAL
VCC
NMI
P34/PO12/TIOCA1/IRQ4-A
P33/PO11/TIOCC0/TIOCD0/TCLKB-A/IRQ3-A
P32/PO10/TIOCC0/TCLKA-A/IRQ2-A
P31/PO9/TIOCA0/TIOCB0/IRQ1-A
P30/PO8/TIOCA0/IRQ0-A
P27/PO7/TIOCA5/TIOCB5/SCK1
P26/PO6/TIOCA5/TMO1/TxD1
P25/PO5/TIOCA4/TMCI1/RxD1
P24/PO4/TIOCA4/TIOCB4/TMRI1
P23/PO3
/TIOCC3/TIOCD3
P21/PO1/TIOCA3/TMCI0/RxD0
P03/TMRI3/SCK4/IRQ11-A/TMS
MD1
P22/PO2/TIOCC3/TMO0/SCK0
42
