Calling up the settings
1
Press MAIN or ZONE2 to select the operating zone with
the remote control.
The button for the selected zone is lit.
2
Press QUICK SELECT.
The Quick Select settings registered to the button you pressed are
called up.
0
The default settings for the input source are as shown below.
GMAIN ZONEH
Button Input source
QUICK SELECT 1 CBL/SAT
QUICK SELECT 2 Blu-ray
QUICK SELECT 3 Media Player
QUICK SELECT 4 HEOS Music
GZONE2H
Button Input source
QUICK SELECT 1 CBL/SAT
QUICK SELECT 2 –
QUICK SELECT 3 Media Player
QUICK SELECT 4 HEOS Music
0
Volume is not registered to Quick Select Plus in the factory default settings.
See “Changing the settings” to register volume to Quick Select Plus. (v p. 149)
Contents Connections Playback Settings Tips Appendix
148
Front panel Display Rear panel Remote Index

Denon AVR-X1700H Specifications

General

Supported radio bands	AM, DAB, DAB+, FM
Radio Data System (RDS)	Yes
Internet radio services supported	Amazon Music, Deezer, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn
Receiver type	Surround
Pre-out channels	0.2
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
Remote (IR) input	1
Composite video in	2
Digital audio coaxial in	-
HDCP version	2.3
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, DTS Virtual:X, Dolby Surround, Dolby TrueHD
Center speaker impedance	16 Ω
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV
Supported graphics resolutions	7680 x 4320
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
Package weight	10600 g
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
