Denon AVR-X1700H User Manual

On Screen Disp.
Select the on-screen display user interface preferences.
o
Volume
Sets where to display the volume level.
Bottom
(Default):
Display at the bottom.
Top: Display at the top.
Off: Turn display off.
0
When the master volume display is hard to see when superimposed text
(closed captioning) or movie subtitles are present, set to “Top”.
o
Info
Displays status of operation temporarily when the input source is
switched.
On
(Default):
Turn display on.
Off: Turn display off.
o
Now Playing
Sets the display time for the playback display when the input source is
“HEOS Music” or “Tuner”.
Always On
(Default) :
Show display continuously.
Auto Off:
Show display for 30 seconds after
operation.
Contents Connections Playback Settings Tips Appendix
181
Front panel Display Rear panel Remote Index

Denon AVR-X1700H Specifications

General

Supported radio bands	AM, DAB, DAB+, FM
Radio Data System (RDS)	Yes
Internet radio services supported	Amazon Music, Deezer, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn
Receiver type	Surround
Pre-out channels	0.2
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
Remote (IR) input	1
Composite video in	2
Digital audio coaxial in	-
HDCP version	2.3
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, DTS Virtual:X, Dolby Surround, Dolby TrueHD
Center speaker impedance	16 Ω
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV
Supported graphics resolutions	7680 x 4320
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
Package weight	10600 g
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
