Diagnostics
Used to check the network connection.
o
Physical Connection
Checks the physical LAN port connection.
OK
Error:
The LAN cable is not connected. Check
the connection.
0
When connected using a wireless LAN, “Connection Wireless(Wi-Fi)” will be
displayed.
o
Router Access
Checks the connection from this unit to the router.
OK
Error:
Failed to communicate with the router.
Check the router settings.
o
Internet Access
Checks whether this unit has access to the Internet (WAN).
OK
Error:
Failed to connect to the Internet. Check
the Internet connection environment or
router settings.
AirPlay
Settings for Apple AirPlay.
On
(Default):
Enables Apple AirPlay.
Off: Disables Apple AirPlay.
Contents Connections Playback Settings Tips Appendix
214
Front panel Display Rear panel Remote Index

Denon AVR-X1700H Specifications

General

Supported radio bands	AM, DAB, DAB+, FM
Radio Data System (RDS)	Yes
Internet radio services supported	Amazon Music, Deezer, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn
Receiver type	Surround
Pre-out channels	0.2
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
Remote (IR) input	1
Composite video in	2
Digital audio coaxial in	-
HDCP version	2.3
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, DTS Virtual:X, Dolby Surround, Dolby TrueHD
Center speaker impedance	16 Ω
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV
Supported graphics resolutions	7680 x 4320
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
Package weight	10600 g
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
