Page #217 background imageLoading...
Page #217 background image
No sound comes out
No sound comes out of speakers.
0
Check the connections for all devices. (v
p. 35)
0
Insert connection cables all the way in.
0
Check that input connectors and output connectors are not reversely connected.
0
Check cables for damage.
0
Check that speaker cables are properly connected. Check that cable core wires come in contact with the metal part on speaker terminals. (v
p. 35)
0
Securely tighten the speaker terminals. Check speaker terminals for looseness. (v p. 35)
0
Check that a proper input source is selected. (v p. 66)
0
Adjust the volume. (v p. 67)
0
Cancel the mute mode. (v p. 67)
0
Check the digital audio input connector setting. (v
p. 165)
0
Check the digital audio output setting on the connected device. On some devices, the digital audio output is set to off by default.
0
When a headphone is plugged into the PHONES jack on the main unit, sound is not output from the speaker terminal and PRE OUT connector.
No sound comes out when using the DVI-D connection.
0
When this unit is connected to a device equipped with a DVI-D connector, no sound is output. Make a separate audio connection.
Contents
Connections Playback Settings Tips Appendix
217
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X2400H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X2400H and is the answer not in the manual?

Denon AVR-X2400H Specifications

General IconGeneral
Receiver typeSurround
Frequency range20 - 20000 Hz
Pre-out channels2 SW
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.08 %
Power output per channel (1KHz@6 Ohm)150 W
Power output per channel (20-20KHz@8 Ohm)95 W
DisplayVFL
HDCP version2.2
Apple dockingNo
Product colorBlack
Audio decodersDTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume controlRotary
Center speaker impedance16 Ω
Supported video modes720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions3840 x 2160
HDMI in8
Audio (L/R) in4
Digital audio coaxial in0
Ethernet LAN (RJ-45) ports1
Multichannel audio input typeRCA
Component video (YPbPr/YCbCr) in2
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Internet radio services supportedDeezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
Audio formats supportedALAC, DSD, FLAC, MP3, WAV
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)500 W
Headphone connectivity3.5 mm
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
CertificationCE, EAC
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height167 mm
Weight9400 g
