Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 179)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 179)
Playback speaker and zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel 2-channel (Pre-out) Can be set in all “Amp Assign” modes. 40
7.1-channel (surround back) 2-channel (Pre-out) Surround Back 41
7.1-channel (front height) 2-channel (Pre-out) Front Height 42
7.1-channel (top front) 2-channel (Pre-out) Top Front 43
7.1-channel (top middle) 2-channel (Pre-out) Top Middle 44
7.1-channel (front Dolby Atmos Enabled speaker) 2-channel (Pre-out) Front Dolby 45
7.1-channel (surround Dolby Atmos Enabled speaker) 2-channel (Pre-out) Surround Dolby 46
5.1-channel (bi-amp connection for front speaker) 2-channel (Pre-out) Bi-Amp 47
5.1-channel + second pair of front speaker 2-channel (Pre-out) Front B 48
5.1-channel
2-channel
(Speaker out)
ZONE2 (Default) 49
0
The sound mode that can be selected varies according to the speaker configuration. See “Sound modes and channel output” (v p. 242) for the sound modes that are
supported.
Contents Connections Playback Settings Tips Appendix
39
Front panel Display Rear panel Remote Index
