Specify a name for the preset
broadcast station (Preset Name)
You can set the name to the preset broadcast station or change it.
Up to 8 characters can be input.
1
Press OPTION when the input source is “Tuner”.
The option menu screen is displayed.
2
Use ui to select “Preset Name”, then press ENTER.
The “Preset Name” screen is displayed.
3
Use o p to select the group of the broadcast station
you want to name.
4
Use ui to select the broadcast station you want to
name, then press ENTER.
5
Use ui to select a name label, then press ENTER.
The screen that lets you edit the Preset Name is displayed.
0
If you select “Set Defaults”, then the unit returns to displaying the
frequency.
6
Enter the characters, then press “OK”.
7
Press OPTION to return to the previous screen.
Contents Connections Playback Settings Tips Appendix
81
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X2400H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X2400H and is the answer not in the manual?

Denon AVR-X2400H Specifications

General IconGeneral
Receiver typeSurround
Frequency range20 - 20000 Hz
Pre-out channels2 SW
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.08 %
Power output per channel (1KHz@6 Ohm)150 W
Power output per channel (20-20KHz@8 Ohm)95 W
DisplayVFL
HDCP version2.2
Apple dockingNo
Product colorBlack
Audio decodersDTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume controlRotary
Center speaker impedance16 Ω
Supported video modes720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions3840 x 2160
HDMI in8
Audio (L/R) in4
Digital audio coaxial in0
Ethernet LAN (RJ-45) ports1
Multichannel audio input typeRCA
Component video (YPbPr/YCbCr) in2
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Internet radio services supportedDeezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
Audio formats supportedALAC, DSD, FLAC, MP3, WAV
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)500 W
Headphone connectivity3.5 mm
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
CertificationCE, EAC
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height167 mm
Weight9400 g
