Denon AVR-X6300H Service Manual

2. PANEL / REMOTE LOCK Selection Mode
2.1. Actions
Switch the PANEL LOCK and REMOTE LOCK modes between on and off.
2.2. Starting up
While holding down buttons "
STATUS
" and "
INFO
" simultaneously, press the power button to turn on
the power.
Select the desired mode using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to conrm.
2.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
CURSOR
f
/
d
" button is pressed.
Press the "
ENTER
" button to set the currently displayed mode and restart the device.
The setting with "
*
" is selected for each mode.
q
L1
–FP/VOL LOCK*On
L2
FP LOCK On
The buttons on the unit and the master volume knob does not function.
w
L1
FP/VOL LOCK*On
L2
–FP LOCK On
The buttons on the unit does not function.
e
L1
FP LOCK On
L2
–FP LOCK Off
The PANEL LOCK mode is turned off.
r
L1
FP LOCK Off
L2
–RC LOCK On
The device cannot be operated by the remote control.
t
L1
RP LOCK On
L2
–RC LOCK Off
The REMOTE LOCK mode is turned off.
131
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X6300H Specifications

General

Receiver type	Surround
Frequency range	10 - 10000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	3.5 mm
Multichannel audio output type	RCA
Display	-
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
Optical drive included	No
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	750 W
Supported video modes	2160p

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	235 mm
Weight	14500 g
