Denon AVR-X6500H User Manual

Connecting 9.1-channel speakers: Second pair of front speakers
This system enables switching playback between front speakers A and B as desired.
.
FHL
SW
C
SL
SBL
FHR
SR
SBR
FLFL
(B) (A)
FRFR
(A) (B)
.
ASSIGNABLE ASSIGNABLE ASSIGNABLE
SPEAKERS
CENTER SURROUND SURROUNDBACK SURROUNDFRONT SURROUNDBACK FRONT
SBR SBL FHR FHLSW C SR SL
FR
(B)
FL
(B)
FR
(A)
FL
(A)
zz
z
The height speakers, ceiling speakers and Dolby Atmos Enabled speakers can
be connected to the HEIGHT1 speaker terminals. Set the speaker to be
connected from “Height” - “Layout” in the menu. (v p. 225)
Contents
Connections Playback Settings Tips Appendix
67
Front panel Display Rear panel Remote Index
