Denon CEOL RCD-N10 User Manual

o
Tuner section
[FM] [AM]
Receiving Range: 87.5 MHz – 107.9 MHz 520 kHz – 1710 kHz
Effective sensitivity: 1.2 μV / 75 Ω/ohms 20 μV
FM Channel separation: 42 dB (1 kHz) –
FM S/N ratio: Monaural : 70 dB
Stereo : 70 dB
FM THD+N (1 kHz): Monaural : 0.4 %
Stereo : 0.4 %
o
Wireless LAN section
Network type (wireless LAN standard): Conforming to IEEE 802.11a/b/g/n
(Wi-Fi
®
compliant)
z
1
Security: WEP 64 bit, WEP 128 bit
WPA/WPA2-PSK (AES)
WPA/WPA2-PSK (TKIP)
Used frequency range: 2.4 GHz, 5 GHz
z1
The Wi-Fi
®
CERTIFIED Logo and the Wi-Fi CERTIFIED On-Product Logo are registered trademarks of the Wi-Fi Alliance.
Contents
Connections Playback Settings Tips Appendix
141
Front/Top
panel
Rear panel
Remote control
unit
Index

Denon CEOL RCD-N10 Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Grey, White
Optical disc player	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Spotify, Tidal
Coloration	Monochromatic
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPS
AC adapter input voltage	230 V
Impedance	6 Ω
Speaker type	2-way
Frequency range	50 - 20000 Hz
RMS rated power	130 W
Woofer diameter	120 mm
Tweeter diameter	30 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	86 dB
Total Harmonic Distortion (THD)	0.4 %
Channels quantity	2 channels
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	MP3, WMA
Card reader integrated	-
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
USB ports quantity	1
Power source	AC
Input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	55 W
Display type	OLED

Weight and Dimensions

Depth	305 mm
Width	280 mm
Height	108 mm
Weight	3400 g
