Denon CEOL RCD-N10 User Manual

o
Using the AM loop antenna
Suspending on a wall
Suspend directly on a wall without assembling.
.
Nail, tack, etc.
Standing alone
Use the procedure shown above to assemble.
When assembling, refer to “AM loop antenna assembly”.
.
o
AM loop antenna assembly
1
Put the stand section through the bottom of the loop
antenna from the rear and bend it forward.
2
Insert the projecting part into the square hole in the
stand.
.
Projecting part
Square hole
Stand
Loop antenna
Contents
Connections Playback Settings Tips Appendix
27
Front/Top
panel
Rear panel
Remote control
unit
Index

Denon CEOL RCD-N10 Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Grey, White
Optical disc player	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Spotify, Tidal
Coloration	Monochromatic
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPS
AC adapter input voltage	230 V
Impedance	6 Ω
Speaker type	2-way
Frequency range	50 - 20000 Hz
RMS rated power	130 W
Woofer diameter	120 mm
Tweeter diameter	30 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	86 dB
Total Harmonic Distortion (THD)	0.4 %
Channels quantity	2 channels
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	MP3, WMA
Card reader integrated	-
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
USB ports quantity	1
Power source	AC
Input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	55 W
Display type	OLED

Weight and Dimensions

Depth	305 mm
Width	280 mm
Height	108 mm
Weight	3400 g
