Denon CEOL RCD-N10 User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
.
2
Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3
Put the rear cover back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
Approx. 23 ft/7 m
30°
Contents
Connections Playback Settings Tips Appendix
8
Front/Top
panel
Rear panel
Remote control
unit
Index

Denon CEOL RCD-N10 Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Grey, White
Optical disc player	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Spotify, Tidal
Coloration	Monochromatic
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPS
AC adapter input voltage	230 V
Impedance	6 Ω
Speaker type	2-way
Frequency range	50 - 20000 Hz
RMS rated power	130 W
Woofer diameter	120 mm
Tweeter diameter	30 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	86 dB
Total Harmonic Distortion (THD)	0.4 %
Channels quantity	2 channels
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	MP3, WMA
Card reader integrated	-
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
USB ports quantity	1
Power source	AC
Input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	55 W
Display type	OLED

Weight and Dimensions

Depth	305 mm
Width	280 mm
Height	108 mm
Weight	3400 g
