Rear panel
For buttons not explained here, see the page indicated in parentheses ( ).
wq e r yt u
q NETWORK connector ······························································ (10)
w Denon Link HD connector ························································· (8)
e HDMI OUT connectors ······························································ (7)
MONITOR (VIDEO) OUT
AMP (AUDIO) OUT
r AUDIO OUT connectors ···························································· (9)
For software recorded in multi-channel, analog signals that have
been down-mixed into 2 channels are output.
t REMOTE CONTROL jacks
Extension jack for future use.
y RS-232C connector
Extension connector for future use.
u AC inlet (AC IN) ········································································ (12)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
