10
NOTE FOR HANDLING OF LASER PICK-UP
Description of the Components
Label
Pin Connector
year
(last figure)
day month quality control No.
Lot No.
lop No.
Oct. Nov. and Dec. are expressed by alphabetical letters
of X, Y and Z.
10 1 10
-1
LD drive currentquality control
The expressed unit is by mA, with omission of the
decimal point as for example, 56.5mA will be ex-
pressed as 565, but the head of English letter means
the control in the manufacturning plant.
Pin No. Description
IN/OUT
1 PD IC Vc IN
2 Vcc IN
3 E OUT
4 D OUT
5 A OUT
6 B OUT
7 C OUT
8 F OUT
KSS-213C
Lot No.
lop
Slide rack
OP Slide base
Object Lens
Actuator cover
PAL-2 Flexible board
Label
Flexible flat cable connector
Z-axis
Y-axis
(Tangental direction)
X-axis
(Radial direction)
+Z-axis direction
+X-axis direction
+Y-axis direction
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
KSS-213C
Flexible flat cable connector
Pin No. Description
IN/OUT
9 GND IN
10 LD LD IN
11 VR IN
12 PD OUT
13 FCS (+) IN
14 TRK (+) IN
15 TRK (−)IN
16 FCS (−)IN
LD
PDIC
14
13
12
11
10
987654321
16
15
TRACKING
LDPDIC
+2.5V +5V
SHORT LAND
FOCUSING
CAUTION: The soldered connecting portion must be bridged when removing CX161.
