Note: 1) F1, F2 Filament
2) NP No pin
3) P1~P16 Anode
4) 1G~6G Grid
5) NX No extend pin
6) Field of vision is a minimum of 29
°
from the upper side, 30
°
from the lower side.
GND Vcc Vout
(Part No. : 393 8021 006)
Pin No.
Connection
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18 19 20 21 22 23 24
P12 P11 P10 P9 P8 P7 P6 P5 P4
F1 F1 NP 1G 2G 3G 4G 5G 6G NX P16
Pin No.
Connection
P3
25 26 27 28 29 30
P2 P1
FL DISPLAY
6-ST-33GK
NP F2 F2
P13P14P15
GP1U271X (IC601)
Remote Control Sensor
Pin Connection
Anode Connection
Hysteresis
R
L
Compararor
NX
GND
V
OUT
Vcc
