23
PARTS LIST OF P.W.B. UNIT ASS'Y
1U-3346 (DCD-485Model) / 1U-3346A (DCD-685Model)
CD BOAD ASS’Y
Ref. No. Part No. Part Name Remarks
SEMICONDUCTORS GROUP
IC101 263 1091 907 IC LA6559
IC102 262 2789 901 IC BU2616F(E2) DCD-685 model only
IC103 263 1090 005 IC LA9241M
IC104 262 1883 905 IC TC9246F-TP1 DCD-685 model only
IC106 262 2903 004 IC LC78625E
IC107 262 1953 903 IC TC7WU04F
IC301 262 2846 909 IC PCM1735E DCD-485 model only
IC303 263 0615 902 IC BA15218F-DXE2 DCD-485 model only
IC304 262 1765 900 IC SM5841BS DCD-685 model only
IC321,322 262 1837 032 IC PCM1702P-L DCD-685 model only
IC323,324 263 0615 902 IC BA15218F-DXE2 DCD-685 model only
IC325 262 0864 006 IC UPC4570C
IC502 263 0693 005 IC M5290P
IC503 268 0074 904 IC ICP-N20T
IC601 262 2904 003 IC UPD78044FGF-188-3B9
IC602 499 0303 004 IC GP1UM271XK
TR101-104 269 0054 901 Transistor DTC144EKT96
TR105 271 0238 908 Transistor 2SA1037KT96(S/R)
TR106 274 0120 002 Transistor 2SD1762(E/F)
TR108,109 269 0085 909 Transistor DTC144TKT96
TR323,324 274 0160 907 Transistor 2SD2144STPU
TR401,402 274 0160 907 Transistor 2SD2144STPU DCD-685 model only
TR403,404 273 0348 904 Transistor 2SC3326
A/B (TAPE)
DCD-485 model only
TR501 274 0120 002 Transistor 2SD1762(E/F)
TR502 272 0083 004 Transistor 2SB1185(E/F)
TR503 272 0025 907 Transistor 2SB562(C)TF
TR504 269 0055 900 Transistor DTA144EKT96
TR505 269 0082 902 Transistor DTC114EKT96
TR506 269 0156 906 Transistor DTA124XKA-T146
TR507 269 0082 902 Transistor DTC114EKT96
D502-509 276 0704 903 Diode 1SR35-400A(T93X)
D510 276 0432 903 Diode 1SS270A TE (TAPE)
ZD101 276 0644 908 Zener diode MTZJ6.8A T77
ZD102 276 0450 901 Zener diode HZS2B-1TD DCD-685 model only
ZD501 276 0644 908 Zener diode MTZJ6.8A T77
ZD502 276 0645 936 Zener diode MTZJ24A T77
RESISTORS GROUP
R101 247 2010 969 Carbon chip 22 kohm 1/10W RM73B--223JT
R102-105 247 2009 941 Carbon chip 6.8 kohm 1/10W RM73B--682JT
R106 247 2010 969 Carbon chip 22 kohm 1/10W RM73B--223JT
R107 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
R108-110 247 2004 920 Carbon chip 47 ohm 1/10W RM73B--470JT
R111 247 2010 969 Carbon chip 22 kohm 1/10W RM73B--223JT
R112 247 2004 920 Carbon chip 47 ohm 1/10W RM73B--470JT
R113 247 2012 925 Carbon chip 100 kohm 1/10W RM73B--104JT
R114 247 2010 956 Carbon chip 20 kohm 1/10W RM73B--203JT
R115 247 2009 909 Carbon chip 4.7 kohm 1/10WRM73B--472JT (1608)
Ref. No. Part No. Part Name Remarks
R116 247 2008 926 Carbon chip 2.2 kohm 1/10W RM73B--222JT
R117 247 2004 920 Carbon chip 47 ohm 1/10W RM73B--470JT
R118 247 2011 984 Carbon chip 68 kohm 1/10W RM73B--683JT
R119 247 2010 914 Carbon chip 13 kohm 1/10W RM73B--133JT
R120 247 2010 956 Carbon chip 20 kohm 1/10W RM73B--203JT
R121 247 2009 909 Carbon chip 4.7 kohm 1/10W RM73B--472JT (1608)
R122 247 2009 983 Carbon chip 10 kohm 1/10W RM73B--103JT
R123 244 2050 920 Metal oxide 120 ohm 1W(NB)RS14B3A121JNBST(S)
R124,125 247 2009 983 Carbon chip 10 kohm 1/10W RM73B--103JT
DCD-685 model only
R126-128 247 2018 903 Carbon chip 0 ohm 1/106W RM73B--0R0KT
DCD-685 model only
R129 247 2010 927 Carbon chip 15 kohm 1/10W RM73B--153JT
R130 247 2006 986 Carbon chip 560 ohm 1/10W RM73B--561JT
R131 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
DCD-685 model only
R132 247 2010 927 Carbon chip 15 kohm 1/10W RM73B--153JT
R133 247 2006 999 Carbon chip 620 ohm 1/10W RM73B--621JT
R134 247 2010 969 Carbon chip 22 kohm 1/10W RM73B--223JT
R135 247 2011 900 Carbon chip 33 kohm 1/10W RM73B--333JT
R136-138 247 2010 969 Carbon chip 22 kohm 1/10W RM73B--223JT
R139 247 2013 908 Carbon chip 220 kohm 1/10W RM73B--224JT
R140 247 2009 983 Carbon chip 10 kohm 1/10W RM73B--103JT
R141,142 247 2010 969 Carbon chip 22 kohm 1/10W RM73B--223JT
R143 247 2006 986 Carbon chip 560 ohm 1/10W RM73B--561JT
R144 247 2012 909 Carbon chip 82 kohm 1/10W RM73B--823JT
R145 247 2011 900 Carbon chip 33 kohm 1/10W RM73B--333JT
R146,147 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
R148 247 2011 926 Carbon chip 39 kohm 1/10W RM73B--393JT
R150 247 2007 985 Carbon chip 1.5 kohm 1/10W RM73B--152JT
R151 247 2010 927 Carbon chip 15 kohm 1/10W RM73B--153JT
R152 247 2010 972 Carbon chip 24 kohm 1/10W RM73B--243JT
R153 247 2010 927 Carbon chip 15 kohm 1/10W RM73B--153JT
R154 247 2011 942 Carbon chip 47 kohm 1/10W RM73B--473JT
R155 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
DCD-685 model only
R156 247 2009 967 Carbon chip 8.2 kohm 1/10W RM73B--822JT
R158 247 2009 967 Carbon chip 8.2 kohm 1/10W RM73B--822JT
R159 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
R160 247 2011 926 Carbon chip 39 kohm 1/10W RM73B--393JT
R161 247 2010 901 Carbon chip 12 kohm 1/10W RM73B--123JT
R162 247 2010 927 Carbon chip 15 kohm 1/10W RM73B--153JT
R163 247 2009 925 Carbon chip 5.6 kohm 1/10W RM73B--562JT
DCD-685 model only
R164 247 2002 964 Carbon chip 10 ohm 1/10W RM73B--100JT
R165 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
R166 247 2011 942 Carbon chip 47 kohm 1/10W RM73B--473JT
R167 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
R168 247 2009 941 Carbon chip 6.8 kohm 1/10W RM73B--682JT
R169 247 2011 900 Carbon chip 33 kohm 1/10W RM73B--333JT
R170 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
DCD-685 model only
R171,172 247 2009 983 Carbon chip 10 kohm 1/10W RM73B--103JT
DCD-685 model only
R173 247 2008 926 Carbon chip 2.2 kohm 1/10W RM73B--222JT
R174 247 2010 985 Carbon chip 27 kohm 1/10W RM73B--273JT
R175 247 2012 912 Carbon chip 91 kohm 1/10W RM73B--913JT
DCD-685 model only
R176 247 2010 998 Carbon chip 30 kohm 1/10W RM73B--303JT
R177 247 2006 931 Carbon chip 360 ohm 1/10W RM73B--361JT
R178 247 2011 913 Carbon chip 36 kohm 1/10W RM73B--363JT
R179 247 2012 954 Carbon chip 130 kohm 1/10W RM73B--134JT
R180,181 247 2018 903 Carbon chip 0 ohm 1/10W RM73B--0R0KT
