PARTS LIST OF CD MECHANISM UNIT
Ref. No. Part No. Part Name Remarks
Q'ty
1
S26 4629 001
Tray (C) 1
2
This part (No.2)doesn't belong to the tray.
Take it down from old tray and use
again when changing the tray.
3
S26 2554 401
Gear cover(S) 1
4
S26 2553 501
Tray gear(S) 1
5
S26 2554 601
Chucking plate 1
6
S26 2629 401
Screw 2.6 x 7 +PTPWH 4
7
S26 2553 701
Chucking yoke 1
8
S14 5249 321
Magnet 1
9
S26 2554 102
Damper 1
10
S26 4629 101
Chucking pulley 1
11
S26 4628 801
Sub chassis Ass'y 1
12-1
S26 2723 601
Coil spring(front) 2
12-2
S26 2723 501
Coil spring(back) 2
13 - Screw 2.6 x 10 +P
No slit type2
4
14
S26 4628 901
Washer 2130 4
17
S26 2555 206
Outsert main chassis(S) 1
18
S33 1950 151
Screw 2.6 x 16 +PTPWH 1
19
S26 2554 701
Drive gear(S) 1
20
S26 2554 504
Contorol cam(S) 1
21
S16 9266 711
Leaf switch 2
22
S15 6472 111
5P connector 1
23
S16 4052 311
Loading P.W.B 1
24
SX2 6251 171
Loading motor Ass'Y 1
25
S26 2553 402
Middle gear 1
26
S26 2553 602
Loading pulley 1
27
S36 5338 700
LM belt 1
28
S26 2527 901
Screw 2.6 x 2.5 +B 1
31
S26 2690 801
Sled shaft 1
32
S26 2723 401
Insulator 4
33
S26 4138 601
Tapping screw 2 x 5 4
34
S26 2562 501
Plate 1
35
S26 2519 101
Coil spring 1
36
S26 2547 701
Center ring 1
37
S88 4848 305
Laser pick up KSS-213C 1
38
S26 2518 802
Gear(A) 1
39
SX2 6259 841
Motor chassis Ass'y 1
40
SX2 6257 691
Motor gear Ass'y 1
41
S16 3967 812
Motor P.W.B. 1
42
S15 7208 511
Leaf switch 1
43
S15 6472 211
6P connector 1
44
S76 2125 515
Screw 2 x 3 +P 1
