28
PARTS LIST OF EXPLODED VIEW
Ref.No. Part No. Part Name Remarks Q'ty
1 1U-3346 CD board ass'y DCD-485 model only 1
1 1U-3346A CD board ass'y DCD-685 model only 1
1-1 Servo & D/A unit
1-2 Power unit
1-3 Display unit
1-4 H/P jack unit
1-5 Power sw unit
2-1 146 2232 208 Front panel DCD-485 model only 1
2-2 - H/P PWB holder DCD-485 model only 1
2 144 2758 003 Front panel DCD-685 model only 1
2 144 2758 016 Front panel Gold model only(685) 1
3 143 1114 001 Window DCD-485 model only 1
3 143 1066 117 Window DCD-685 model only 1
4-1 146 2141 409 Inner panel DCD-685 model only 1
4-1 146 2141 412 Inner panel Gold model only(685) 1
4-2 - H/P PWB holder DCD-685 model only 1
5 113 1849 029 Function knob 1
5 113 1849 074 Function knob Gold model only(685) 1
6 113 1904 003 Tact knob(4P) DCD-485 model only 1
7 113 1850 005 Tact knob (6P) Gold model only(685) 1
7 113 1850 018 Tact knob (6P) DCD-685 model only 1
8 412 2814 044 Card spacer (L=6) DCD-685 model only 1
9 412 4782 006 Support bracket(F) DCD-485 model only 1
10 412 4783 005 Support bracket(B) DCD-485 model only 1
11 113 9213 000 P•knob (P) ass'y 1
11 113 9213 084 P•knob (P) ass'y Gold model only(685) 1
12 112 0851 002 Knob (Maru) 1
12 112 0851 015 Knob (Maru) Gold model only(685) 1
13 112 0811 013 Knob (Fuji) DCD-685 model only 1
13 112 0811 000 Knob (Fuji) Gold model only(685) 1
15 461 0501 005 Rubber sheet DCD-685 model only 3
20 411 1386 509 Chassis 1
21 105 1318 245 Back panel DCD-485 model only 1
21 105 1318 258 Back panel DCD-685 model only 1
22 102 0604 003 Top cover 1
22 102 0604 016 Top cover Gold model only(685) 1
23 104 0260 100 Foot ass'y 4
24 412 4784 004 Semko bracket 1
25 477 0308 009 Hole plug 1
26 445 0124 008 Flat cable clamp 1
27 337 0064 003 CD mech(KSL-2130CCM) 1
28 146 2233 100 Loader panel 1
28 146 2233 113 Loader panel Gold model only(685) 1
29 415 9016 035 P.C.B holder 2
30 412 2814 015 Card spacer (L=14) 1
31 417 0613 006 Heat sink(PH-0125-M) AS101 1
32 417 0579 001 Heat sink AS102 1
33 233 6369 002 Power trans(E2/EK) 1
50 204 6504 005 14P PH-SAN con cord CX141 1
51 204 0536 011 6P PH-PH con.cord 1
52 203 8299 056 5P KR-KR con cord 1
53 009 0159 013 16P FFC cable 1
54 009 0133 039 27P FFC 1
55 203 6514 018 4P PH-PH shield cord 1
56 203 5132 051 3P VH-VH conn.cord 1
57 203 8363 034 5P PH-PH conn cord 1
513 2358 007 E2 laser caution 1
513 1642 002 No. sheet 1
Ref.No. Part No. Part Name Remarks Q'ty
SCREWS
40 473 7002 021 3X8 CBTS (S)-B DCD-485 model only 22
DCD-685 model only 20
41 477 0064 107 Fixing screw 5
42 473 7004 016 4X6 CBTS (S)-Z 2
43 473 7508 017 3X10 CBTS (P)-B DCD-485 model only 11
DCD-685 model only 7
44 473 8044 017 Special screw DCD-485 model only 2
DCD-685 model only 1
45 473 8007 025 3X8 cup screw 3
46 477 0263 005 3P. swelling screw 4
46 477 0263 018 3P. swelling screw Gold model only 4
47 473 7002 034 3X6 CBTS (S)-B 3
