7
¥¥¥
Fig. 4 In “03 F on”
¥¥¥
¥¥¥¥¥¥¥¥¥
Fig.
5 In “03 F on”
* Press the PLAY button again.
* “04 t on” is displayed. Tracking, CLV, and slide servo will be actuated.
* Monitor HF signal using the test terminals, HF of CX053 (Pin No. 1 ) and
VC of CX063 (Pin No. 5 : 2.5V ref. signal). Check that the signal’s amplitude
is 1.5V
â
0.3Vp-p. (Refer to Fig. 6)
¥¥¥
Fig. 6 In “04 t on”
A ( A = 1.5 ± 0.3 V
P-P
)
