29
ENGLISH
Basic versionSimple version InformationAdvanced version
Menu map
For menu operations, see the following page.
Setting items Number Detailed items Description Page
1 Speaker Setup
Once these items are set, there is no need to
set them again unless the speaker layout or
the connected speakers have been changed.
1-1 Speaker Confi g. Select speaker confi guration and size (bass reproduction capability). 7
1-2 Bass Setting Set subwoofer and LFE signal range playback. 8
1-3 Distance Set distance from listening position to speakers. 8
1-4 Channel Level Set the volume of the test tone to be the same when it is output from each
speaker.
9
1-5 Crossover Freq. Set the maximum frequency of the bass signal output from each channel to
the subwoofer.
9
2 Input Setup
Displayed items of the “Input Setup” menu
differs, depending on the selected input
source.
2-1 Input Assign Changes input connector assignment. 31
2-2 Auto Preset Uses the auto preset function to program radio stations. 32
2-3 Preset Skip Sets the preset memories that you do not want to display when tuning. 32
2-4 Video Select Makes the video settings. 32
2-5 Input Mode Sets the audio input mode and decode mode. 32
2-6 Source Level Adjusts the playback level of the audio input. 33
2-7 Playback Mode Makes settings for iPod playback. 33
3 Option Setup 3-1 Volume Control Sets the volume setting. 33
3-2 Other Setup Makes various other settings. 34
A-1 Surround Parameter Adjusts surround sound parameters. 34
A-2 Tone Adjusts the tonal quality of the sound. 36
A-3 NIGHT MODE Optimized setting for late-night listening.
Compress dynamic range (difference between loud and soft sounds).
36
A-4 RESTORER Uncompresses compressed sources and apply bass boost for richer sound. 36
A-5 Audio Delay Compensates for incorrect timing between video and audio. 36
How to make detailed settings
1.AVR391E3ENG4th100602.inddSec:291.AVR391E3ENG4th100602.inddSec:29 2010/06/0414:29:272010/06/0414:29:27
To Next Page
