5
DN-S3500
5. Power P.W.B.
(1) Remove 6 screws 69, a screws 72 and a screws 73.
(2) Detach Power P.W.B.
6. Main P.W.B.
(1) Short-circuit the short land above.
(2) Remove a screws 65 and a screws 66.
(3) Disconnect FFC Cable and FPC Cable.
(4) Detach Main P.W.B.
Note:
z Do not pull out aslant to prevent FFC cable damage.
69
69
69
69
72
73
Power P.W.B.
Short land for laser diode
Main P.W.B.
FPC Cable
FFC Cable
66
65
