MIDI Control
MIDI command list
Items
(VFD Parameter)
MIDI command
Notes
Command Number Value
1 Tr number MSB
CC : 0xBn
64
0-99
100-109 : “-0”
to “-9”
110 : “--”, 111
: “ ”
–
2 Tr number LSB 65
3 Time mini 66
4 Time sec 67
5 Time frame 68
6 Pitch POL 69
‘0
‘+‘ 1
‘-‘ 2
7 Pitch MSB 70 0-99
100-109 : “-0”
to “-9”
110 : “--”, 111
: “ ”
8 Pitch LSB 71
9 Track Position
72 normal
73 reverse
0-100 %
10 Point indicator
58 ON
59 OFF
0 to 99
(=left edge to right
end)
11 Segment 1-1 MSB 1
0-15
ASCII+original MSB
•Segment command must be sent
to a pair in order of MSB,LSB.
12 Segment 1-2 MSB 2
13 Segment 1-3 MSB 3
14 Segment 1-4 MSB 4
15 Segment 1-5 MSB 5
16 Segment 1-6 MSB 7
17 Segment 1-7 MSB 8
18 Segment 1-8 MSB 9
19 Segment 1-9 MSB 10
20 Segment 1-10 MSB 11
21 Segment 1-11 MSB 12
22 Segment 1-12 MSB 13
23 Segment 1-13 MSB 88
24 Segment 1-14 MSB 89
25 Segment 1-15 MSB 90
26 Segment 1-16 MSB 91
27 Segment 1-1 LSB 33
ASCII+original LSB
28 Segment 1-2 LSB 34
29 Segment 1-3 LSB 35
30 Segment 1-4 LSB 36
31 Segment 1-5 LSB 37
32 Segment 1-6 LSB 39
33 Segment 1-7 LSB 40
34 Segment 1-8 LSB 41
35 Segment 1-9 LSB 42
36 Segment 1-10 LSB 43
37 Segment 1-11 LSB 44
38 Segment 1-12 LSB 45
39 Segment 1-13 LSB 92
40 Segment 1-14 LSB 93
41 Segment 1-15 LSB 94
42 Segment 1-16 LSB 95
Items
(VFD Parameter)
MIDI command
Notes
Command Number Value
43 Segment 2-1 MSB
CC : 0xBn
14
0-15
ASCII+original MSB
44 Segment 2-2 MSB 15
45 Segment 2-3 MSB 16
46 Segment 2-4 MSB 17
47 Segment 2-5 MSB 18
48 Segment 2-6 MSB 19
49 Segment 2-7 MSB 20
50 Segment 2-8 MSB 21
51 Segment 2-9 MSB 22
52 Segment 2-10 MSB 23
53 Segment 2-11 MSB 24
54 Segment 2-12 MSB 25
55 Segment 2-13 MSB 108
56 Segment 2-14 MSB 109
57 Segment 2-15 MSB 110
58 Segment 2-16 MSB 111
59 Segment 2-1 LSB 46
ASCII+original LSB
60 Segment 2-2 LSB 47
61 Segment 2-3 LSB 48
62 Segment 2-4 LSB 49
63 Segment 2-5 LSB 50
64 Segment 2-6 LSB 51
65 Segment 2-7 LSB 52
66 Segment 2-8 LSB 53
67 Segment 2-9 LSB 54
68 Segment 2-10 LSB 55
69 Segment 2-11 LSB 56
70 Segment 2-12 LSB 57
71 Segment 2-13 LSB 112
72 Segment 2-14 LSB 117
73 Segment 2-15 LSB 118
74 Segment 2-16 LSB 119
