DP-200USB
23
Ref No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601 941239000500S
IC(LA3161)
417-F606-720
1 *
Q601 90M-BA001610R
CHIP TRANSISTOR(DTA124TKAT146)
416-HDJ9700-210
1
Q602,Q603 00D9410046406
TRANSISTOR(2SC4695)
416-DAIA-273
2
Q604 00D9580040400
DIGITAL TRANSISTOR(DTC124TS TAPING OR 2SC4120)
416-1330-020
1
Q605 00D9587057603
TRANSISTORS(2SC3330U-AC)
416-DJ1900-023
1
D601,D602 00D9410046901
SWITCHING DIODE(1SS355,UMD2,SMD,TAPING)
414-CD1000-075
2
D603 941209000730S
DIODE(1N4001,1A/50V,TAPING 52mm)
414-DJ2500-110
1
D604 00D2760761904
ZENER DIODE(MTZJ9.1-B,1/2W,T-77)
414-3113-007
1
RESISTOR GROUP
R602 nsp
CHIP RESISTOR(100 OHM,1/8W,J,0805,150V)
412-DV330-304
1
R603 nsp
CHIP RESISTOR(470 OHM,1/10W, 0603,J,TP,50V)
412-CDVD2001-545
3
R604 nsp
CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ,50V)
412-CDVD2001-532
2
R606 nsp
CHIP RESISTOR(150K OHM,1/10W,0603,J,TP ,50V)
412-007USB-688
2
R607 nsp
CHIP RESISTOR(9.1K OHM,1/10W,0603,J,TP ,50V)
412-CDVD2001-543
2
R608 nsp
CHIP RESISTOR(200 OHM,1/10W,J,TP 0603,50V)
412-MH2-1138
2
R609,R610 nsp
CHIP RESISTOR(680 OHM,1/10W,J,TP ,50V)
412-900-1060
2
R611 nsp
CHIP RESISTOR(470 OHM,1/10W, 0603,J,TP,50V)
412-CDVD2001-545
3
R612 nsp
CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ,50V)
412-CDVD2001-532
2
R613 nsp
CHIP RESISTOR(150K OHM,1/10W,0603,J,TP ,50V)
412-007USB-688
2
R614 nsp
CHIP RESISTOR(9.1K OHM,1/10W,0603,J,TP ,50V)
412-CDVD2001-543
2
R615 nsp
CHIP RESISTOR(200 OHM,1/10W,J,TP 0603,50V)
412-MH2-1138
2
R616 nsp
CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP ,50V)
412-CDVD2001-537
4
R617 nsp
CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V)
412-CDVD2001-540
4
R618 nsp
CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP ,50V)
412-CDVD2001-537
4
R619 nsp
CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V)
412-CDVD2001-540
4
R620,R621 nsp
CHIP RESISTOR(6.2KOHM,1/10W,F,TP 0603,50V)
412-900-985
2
R622 nsp
CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ,50V)
412-CDVD2001-534
1
R623,R624 nsp
CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V)
412-CDVD2001-540
4
R625 nsp
CHIP RESISTOR(390 OHM,1/4W,J,TP 1206,150V)
412-200USB-1341
1
R627,R628 nsp
CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP ,50V)
412-CDVD2001-537
4
R629 nsp
CHIP RESISTOR(220K OHM,1/10W, 0603,J,TP,50V)
412-007USB-678
1
R630 nsp
CHIP RESISTOR(470 OHM,1/10W, 0603,J,TP,50V)
412-CDVD2001-545
3
CAPACITORS GROUP
C601 nsp
CHIP CAPACITOR(0.1uF/50V,Z,0603 TYPE,Y5V)
413-DCM280-773
2
C601 nsp
CHIP CAPACITOR(0.1uF/50V,Z,0603 TYPE,Y5V)
413-DCM280-773
2
C602 00D9587032806
ELEC. CAPACITOR(100uF/16V,M,105 ,TAPING 6.3*7,MINI)
413-HT801K-193
4
C603 00D9587055304
ELEC. CAPACITOR(4.7uF/50V,M,105 ,TAPING 4*7,MINI)
413-HT801K-191
2
C604 nsp
CHIP CAPACITOR(100pF/50V,J,0603 TYPE,NPO)
413-DCM280-767
4
C605 nsp
CHIP CAPACITOR(470pF/50V,J,0603 TYPE,NPO)
413-007USB-786
2
C606 00D9587032301
POLYESTER CAPACITOR(0.027uF/50V,J,TAPING)
413-HT8015-161
2
C607 00D9587032204
POLYESTER CAPACITOR(0.0082uF/50V,J,TAPING)
413-HT8015-160
2
C608 941134000520S
E.C.(4.7uF/25V,MINI)
413-SMX701-712
4
C609 nsp
ELEC. CAPACITOR(33uF/16V,M,105 ,TAPING 5*7,MINI)
413-HDJ201-350
2
C610 nsp
CHIP CAPACITOR(100pF/50V,J,0603 TYPE,NPO)
413-DCM280-767
4
C611 00D9587055304
ELEC. CAPACITOR(4.7uF/50V,M,105 ,TAPING 4*7,MINI)
413-HT801K-191
2
C612 nsp
CHIP CAPACITOR(470pF/50V,J,0603 TYPE,NPO)
413-007USB-786
2
C613 nsp
ELEC. CAPACITOR(33uF/16V,M,105 ,TAPING 5*7,MINI)
413-HDJ201-350
2
C614 00D9587032301
POLYESTER CAPACITOR(0.027uF/50V,J,TAPING)
413-HT8015-161
2
C615 00D9587032204
POLYESTER CAPACITOR(0.0082uF/50V,J,TAPING)
413-HT8015-160
2
C616 941134000520S
E.C.(4.7uF/25V,MINI)
413-SMX701-712
4
C617-C618 nsp
CHIP CAPACITOR(4700pF/50V,K,0603 TAPING,X7R)
413-007USB-789
4
C619 00D9587032806
ELEC. CAPACITOR(100uF/16V,M,105 ,TAPING 6.3*7,MINI)
413-HT801K-193
4
C621 00D9587032806
ELEC. CAPACITOR(100uF/16V,M,105 ,TAPING 6.3*7,MINI)
413-HT801K-193
4
PH/LI PCB ASS'Y
To Next Page
