Denon DP-200USB Service Manual

DP-200USB
24
Ref No. Part No. Part Name Remarks Q'ty New
C622 941134000430S ELEC.CAPACITOR(22uF/25V,M,TAPING 5*11) 413-200USB-1119 1
C623 941134000510S ELEC. CAPACITOR(220uF/16V,M,105( ,TAPING 6*7,MINI) 413-RMX30-883 1
C624 941134000520S E.C.(4.7uF/25V,MINI) 413-SMX701-712 4
C625 nsp CHIP CAPACITOR(4700pF/50V,K,0603 TAPING,X7R) 413-007USB-789 4
C626 941134000520S E.C.(4.7uF/25V,MINI) 413-SMX701-712 4
C627 nsp CHIP CAPACITOR(4700pF/50V,K,0603 TAPING,X7R) 413-007USB-789 4
C628 00D9587032806 ELEC. CAPACITOR(100uF/16V,M,105 ,TAPING 6.3*7,MINI) 413-HT801K-193 4
C629,C630 nsp CHIP CAPACITOR(100pF/50V,J,0603 TYPE,NPO) 413-DCM280-767 4
OTHER PARTS GROUP
CN601 nsp
3P 2.5CONNECTOR WIRE
(UL2547#28*2C TS GRAY L=340mm)
404-QFX-2425 1
CN602 nsp
2P 2.0 CONNECTOR WIRE
(L=270mm,UL1007#26 TS BLACK RED)
404-200USB-3076 1
CN603 00D9587066403 3P SOCKET(CKM2501WV-3P.180°WHTIE) 404-HV3500K-623A 1
JR1-JR4 nsp CHIP RESISTOR(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414 4
L203,L204 90M-FC900430R CHIP BEAD(SBK201209T-601Y-S) 415-1300-240 5
L601,L602 90M-FC900430R CHIP BEAD(SBK201209T-601Y-S) 415-1300-240 5
L605 90M-FC900430R CHIP BEAD(SBK201209T-601Y-S) 415-1300-240 5
RELY1 941682000440S RELAY(V23079-A2003-B301) 415-DJU5000-297 1 *
SW601 00D9410014001 SLIDE SW(SBB-22-14) 403-PXE90-028 1
nsp
GROUND WIRE FOR MECHA
(L=50mm,AWM1007 AWG22,BLACK)
406-CDMIX1-518 1
nsp CABLE TIE 504-S100-004 1

Denon DP-200USB Specifications

General

Type	Belt-drive audio turntable
CD player	No
Product color	Silver
AC adapter frequency	50 Hz
AC adapter input voltage	230 V
Power consumption (typical)	12 W
USB version	2.0
USB ports quantity	1

Weight and Dimensions

Depth	98 mm
Width	360 mm
Height	368 mm
Weight	3200 g
