Denon DP-200USB Service Manual

DP-200USB
25
Ref No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC901 00D9587058107 IC(BA05T,3PIN) 417-CDN34A-314 1 *
IC902 00D9410022103 IC(NJM7812FA 3PIN) 417-BJ1900L-231 1 *
D901-D908 00D9410046804 DIODE(1N4002/1N4002TA,1A/100V,TAPING) 414-DV300-5014 8
D909 00D9587056701 DIODE(RB160M-30,SOD-123) 414-900-208 1
CAPACITORS GROUP
C01 00D9580045308 MEX CAPACITOR(0.1uF/250V,K,BULK) 413-PROTT1-432 1
z
C02 90M-DK100940R AC SAFETY CAPACITOR(4700pF/250V,M,BULK,Y5V) 413-1431-104 1
z
C03 90M-DK100940R AC SAFETY CAPACITOR(4700pF/250V,M,BULK,Y5V) 413-1431-104 1
C901 00D9410055604 METAL POLYESTER CAPACITOR(0.1uF/AC125V,K) 413-DJ3500-884 2
C902 941134000530S ELEC. CAPACITOR(470uF/10V,M, 105 ,TAPING 8*12) 413-HT8015-169 1
C903 00D9587053209 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035 2
C904 00D9580044105 ELEC. CAPACITOR(1000uF/25V,M, 105 ,BULK 10*20) 413-DJ1900-111 1
C905 00D9587055906 ELEC.CAPACITOR(100uF/16V,M,105 ,TAPING 5*11) 413-PXE90-109 1
C906 00D9587053209 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035 2
C907 00D9410055604 METAL POLYESTER CAPACITOR(0.1uF/AC125V,K) 413-DJ3500-884 2
C908 00D9587053500 ELEC. CAPACITOR(2200uF/16V,M, 105 ,BULK 13*21) 413-3113-053 1
OTHER PARTS GROUP
AC-L nsp PIN(NS-1105) 300-B604-114 2
AC-N nsp PIN(NS-1105) 300-B604-114 2
ATOA nsp LEAD WIRE(L=370mm,AWM1617 AWG22,RED) 406-DJ5500-680 2
BTOB nsp LEAD WIRE(L=370mm,AWM1617 AWG22,RED) 406-DJ5500-680 2
CN1 nsp
2P 2.0 CONNECTOR WIRE
(L=210mm,UL1007#26 TS BLUE/WHITE)
404-200USB-3074 1
CN901 941644000540S 4P SOCKET(CKM2501WV-4P 180°WHITE) 404-HV3500K-629A 1
CN902 941644000550S 2P SOCKET(CKM2001WV-2P,180°WHITE) 404-HP1010K-257A 2
CN903,CN904 941644000560S 2P SOCKET(CKM2001WR-2P 90°WHITE) 404-DJ3000-847A 2
z
F01 941652000300S FUSE(250mA/250V,UL/CSA,5*20mmSLOW) E3 422-BJ2300A-021 1 *
z
F01 941652000420S FUSE(T125mA/250V,VDE/UL) E2 422-Q2231-084A 1 *
z
FL1 00D9410022608 FILTER(FKOB160MH02) 415-1300-239 1
JR1,JR2 nsp CHIP RESISTOR(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414 2
SW1 941661000320S POWER SW(SDDLB1177U-HF3) 403-C304-218 1
SW2 00D9410058708 PUSH SW(SPEC12HC12-HF,L=12.5) 403-300F-255 1
nsp 1P GROUND WIRE(L=190mm,AWM1617,AWG22,BLACK) 406-BJR100-999 1
nsp CERAMIC TUBE ( 4*2*11.5mm ) 605-KMD510P-034 8
nsp FUSE CLIPS(FS-001) F01 420-KT350A-004 2
nsp FUSE COVER 504-DJ2500J-046 1
nsp FUSE LABEL(20*4mm,t=0.08mm) E2 501-200UBKE2-1176 1 *
nsp FUSE LABEL(20*4mm,t=0.08mm) E3 501-200UBKE3-1176 1 *
nsp GROUNG WIRE(L=80mm,AWM1007 AWG22.BLACK) 406-DJ100-550 1
nsp HEAT SINK((AL,HW-7004)) 425-ST150-064 1 *
nsp HEAT-SHRINKABLE TUBE 605-HDJ201F-050 0 *
nsp SCREW(3*8mm TTB) 602-2002-077 2
nsp SCREW(3*L8) 602-HP1010K-175 3
SPEED/AC SW/AC/DC PCB ASS'Y
