Denon DP-200USB Service Manual

DP-200USB
30
Ref.No. Part No. Part Name
Remarks
Q'ty New
13 941319000600S TONE ARM ASS' Y BKE2, BKE3 704-200K-8140 1 *
13 941319000610S TONE ARM ASS' Y SPE2 704-200SP-8141 1 *
13-1 - TONEARM SETTING & HEADSHELL ASS'Y BKE2, BKE3 701-200K-4465 1 *
13-1 - TONEARM SETTING & HEADSHELL ASS'Y SPE2 701-200SP-4469 1 *
13-2 - ROTARY SHAFT & SPRING ASS'Y 703-SL34F-058 1
13-3 - BALANCE WEIGHT HOLDER PIN 200-SL24F-118 1
13-4 00D9410003711 CARTRIDGE(CN-6516[M-6516]) 402-F804-065 1
13-4-1 00DDSN84 STYLUS 1
13-5 -
TONE ARM SHILED WIRE
(UL1571,32AWG,WHITE,370mm)
407-PXE90-090 1
13-6 - TONE ARM SHILED WIRE(UL1571,32AWG,RED,370mm) 407-PXE90-091 1
14 941319000640S SWITCH& SET ASS'Y 704-200USB-8142 1
14-1 - SWITCHING SETING ASS'Y 701-SL24F-191 1
14-2 - LEAF SW ASS’Y 704-F601-1361 1
14-3 - LEAF SW(LSA-1123-4,2PIN) 403-SL24F-011 1
14-4 - SCREW(2*8 ,PTP) 602-K680-088 1
15 nso TRANSFORMER & AC CORD ASS'Y BKE2,SPE2 704-200USBE2-8157 1 *
15 nsp TRANSFORMER & AC CORD ASS'Y BKE3 704-200USBE3-8158 1 *
z
15-1 nsp AC PCB ASS'Y BKE2,SPE2 704-200USBE2-8156 1 *
z
15-1 nsp AC PCB ASS'Y BKE3 704-200USB-8232 1 *
15-2 nsp AC SW PCB ASS'Y 704-200USB-8138 1 *
15-3 941611000060S AC POWER CORD(L=1980+/-50mm,VDE TYPE) BKE2,SPE2 409-3004-016E 1
15-3 00D9410039109 AC POWER CORD(L=2130mm,UL TYPE) BKE3 409-HMD5000-053A 1
z
15-4 941101000080S TRANSFORMER(AC230V,50Hz) BKE2,SPE2 411-200USB-736 1 *
z
15-4 941101000090S TRANSFORMER(AC120V,60Hz) BKE3 411-200USB-735 1 *
15-5 nsp FUSE LABEL(20*4mm,t=0.08mm) BKE2,SPE2 501-200UBKE2-1176 1 *
15-5 nsp FUSE LABEL(20*4mm,t=0.08mm) BKE3 501-200UBKE3-1176 1 *
16 00D9410001001 45 RPM ADAPTOR 100-H200-016 1
17 941411000630D STRAIN RELIEF 100-29FBKEU-144 1
18 nsp BOTTOM PLATE BKE2 100-200-326BS 1
18 nsp BOTTOM PLATE BKE3 100-200KE3-326BS 1
18 nsp BOTTOM PLATE SPE2 100-200SP-326B 1
19 00D9410001603 PENDULUM(L) 100-SL24F-234 1
20 00D9410001700 PENDULUM(M) 100-SL24F-235 1
21 941412000110D SELECT RECORD KNOB (ABS BLACK) BKE3 100-200K-236 1 *
21 941412000120D SELECT RECORD KNOB (ABS SILVER) SPE2 100-200SP-236 1 *
22 00D9410002000 LIFTER(ABS BLACK) 100-SL24F-238 1
23 00D9410002408 SPEED BRACKER ASS'Y 100-SL24F-242 1
24 00D9410002505 SPEED SUPPORT 100-SL24F-243 1
25 941412000650S SELECTOR 100-SL24F-245 1
26 00D9410002806 SELECT PLATE 100-SL24F-247 1
27 00D9410010403 FOOT(ABS) 100-PXE90-332 2
28 941412000100D SOUARE KNOB BKE2, BKE3 100-200K-1662 1 *
28 941412000130D SOUARE KNOB SPE2 100-200SP-1662 1 *
29 941401000140D CHASSIS BKE2 100-200K-2606 1 *
29 941401000150D CHASSIS BKE3 100-200KE3-2606 1 *
29 941401000180D CHASSIS SPE2 100-200SP-2606 1 *
30 941412000160D KNOB BKE2, BKE3 100-200K-2607 2 *
30 941412000170D KNOB SPE2 100-200SP-2607 2 *
31 941412000190D POWER BUTTON BKE2, BKE3 100-200K-2608 1 *
31 941412000200D POWER BUTTON SPE2 100-200SP-2608 1 *
32 941412000210D RECORD BUTTON BKE2, BKE3 100-200K-2609 1 *
32 941412000220D RECORD BUTTON SPE2 100-200SP-2609 1 *
33 00D9410003009 TONEARM SHAFT SET 200-SL24F-107 1
34 00D9410003504 COPPER WASHER 200-SL24F-117A 2
35 00D9410002903 TURNTABLE(AL) 200-F703-203 1
36 00D9410003601 CONTROL PLATE 300-SL24F-126 1
37 nsp PLATE 300-HPR200-1622 2 *
38 nsp 1P GROUNG WIRE(L=150mm,AWM1015 AWG22,BLACK) 406-120-763 1
39 941612000720S SIGNAL WIRE(L=1200mm) 408-200USB-094 1
40 941541000370D SOFTWARE DISC 429-200USB-051 1 *

Denon DP-200USB Specifications

General

Type	Belt-drive audio turntable
CD player	No
Product color	Silver
AC adapter frequency	50 Hz
AC adapter input voltage	230 V
Power consumption (typical)	12 W
USB version	2.0
USB ports quantity	1

Weight and Dimensions

Depth	98 mm
Width	360 mm
Height	368 mm
Weight	3200 g
