Denon DP-200USB Service Manual

DP-200USB
31
Ref.No. Part No. Part Name
Remarks
Q'ty New
41 00D9410003902 CAUTION LABEL(70*10mm,t=0.1mm) 501-DP29FK-823 1
42 00D9410025401 LABEL(BARE,36*8mm,t=1.2mm) 501-DV300-1067 1 *
44 nsp RATING LABEL(97*25mm,t=0.08mm) BKE2,SPE2 501-200UE2-2176 1 *
44 nsp RATING LABEL(97*25mm,t=0.08mm) BKE3 501-200UE3-2176 1 *
45 nsp SEGREGATE SHEET(87.3*62.5*0.6t) 501-200-2178 1 *
46 nsp SEGREGATE SHEET(141.5*82*0.6t) 501-200-2179 1 *
47 nsp WIRE MOUNT(FW-2-3M,WHITE) 504-ST100-118 1
48 00D9410005803 NUT 601-SL24F-011 1
49 00D9410007209 SPRING 603-MD26-059 1
50 00D9410007403 SPRING(SUS,304,WPB) 603-SL24F-067 1
51 00D9410007500 SPRING(SUS,304,WPB) 603-SL24F-068 1
52 00D9410007607 SPRING(SUS,304,WPB) 603-SL24F-069 1
53 00D9410008101 SPRING(PLAY,STOP KNOB) 603-SL24F-076 3
54 941472000660S SPRING 603-SL24F-079 1
55 00D9410008004 SPRING 603-L100-103 1
56 941472000670S PLAY SPRING 603-200-372 1
57 941472000680S STOP SPRING 603-200-373 1
58 00D9410008703 RUBBER 604-SL24F-036A 4
59 00D9410008907 MOTOR PLASTIC CUSHION 604-SL24F-038 3
60 00D9580035402 CUSHION RUBBER FOR TRANSFORMER 604-DJ1900-064 2 *
61 00D9410008800 BELT 604-PXE90-076 1
62 941409000690S SLIPMAT 604-DP29FK-205A 1
63 00D9410009100 WASHER 606-F200-006 1
64 00D9410009207 E-RING WASHER (3mm) 606-F200-011 2
65 00D9410035307 E-RING WASHER (5mm) 606-F200-012 1
66 00D9410009401 CS WASHER (3mm) 606-F200-013 1
67 00D9410009508 WASHER 606-H200-019 1
68 00D9410010005 WASHER 606-SL24F-055 1
69 00D9580034908 SCREW(SAE1018,PTP, 3*L10) 602-M400-055 4
70 00D9580035606 SCREW(SAE1018,WPTP,M3*8) 602-B600-056 3
71 00D9410006006 SCREW(SAE1018,PTP, 3*L8) 602-B600-057 9
72 00D9410005405 SCREW(3*16mm) 602-B600-059 2
73 00D9410006103 SCREW 602-B600-072 4
74 00D9410006200 SCREW(2*10mm JMB BLACK) 602-MD26-081 1
75 00D9410006404 SCREW(PTP) 602-SL24F-092 4
76 00D9410006501 SCREW(PTP) 602-SL24F-094 2
77 00D9410006608 SCREW 602-SL24F-095 1
78 00D9410006802 SCREW(M3*9 PTP) 602-SL24F-097 4
79 00D9410006909 SCREW 602-SL24F-098 2
80 00D9580034801 SCREW(SAE1018,PTP,M2.6*L8) 602-SL24F-099 10
81 941519000700S SCREW(WPTP,2.6*6,W=7.5) 602-WPTP2606-660Z 4
82 941519000710S SCREW(WPTP, 2.6*L7,CAP 10) 602-DV300-5023 2
83 nsp INSULATION SHEET(58*26.4*0.5t) 501-200-2200 1 *
84 00D9410010102 WASHER 606-SL24F-056 1
85 nsp
LOCKING CABLE CLIP
(WC-1AM-M9B, 5.6,L=35.6mm,BLACK)
504-HV3500K-033 1

Denon DP-200USB Specifications

General

Type	Belt-drive audio turntable
CD player	No
Product color	Silver
AC adapter frequency	50 Hz
AC adapter input voltage	230 V
Power consumption (typical)	12 W
USB version	2.0
USB ports quantity	1

Weight and Dimensions

Depth	98 mm
Width	360 mm
Height	368 mm
Weight	3200 g
